3BSE008538R1 | Terminator for Modulebus. | Improve the stability of bus communication

Product ID:3BSE008538R1
ABB Type Designation:TB807
Catalog Description:TB807 Modulebus terminator
Long Description:Terminator for Modulebus.
Product Net Depth / Length:13 mm
Product Net Height:19 mm
Product Net Width:17 mm
Product Net Weight: 0.01kg

Features
Ensures signal integrity: Terminates the Modulebus network, preventing signal reflections.
Simple installation: Easy to install, requiring no configuration.
Compact design: Saves valuable space in your control cabinet.
CE marked: Meets relevant safety and compliance standards.

3BSE008538R1 Functions and Applications:
The 3BSE008538R1 bus terminator is usually used in the end of the bus network, the main role is to prevent the signal from reflecting at the end of the cable, so as to maintain the integrity of the signal and the stability of the network. It can also reduce signal interference and improve the stability of bus communication.

This terminator can absorb the signal energy on the bus, further reducing signal reflection and distortion by matching the characteristic impedance of the bus cable (usually 120 ohms).
It is designed to be plug and play for rapid deployment and maintenance in the network.
3BSE008538R1 Features:
High quality manufacturing: ensures long-term reliability and stability for continuous operation in industrial environments.
Modular design: 3BSE008538R1 is easy to install and protect, can support a variety of module bus standards, with good compatibility.
Easy maintenance: When maintenance or replacement is required, the terminator can be easily removed and replaced without complicated operations.
