Product Overview
The Fisher 56AMXN is a high-performance industrial level transmitter, meticulously designed to provide accurate and reliable level measurement in a wide range of industrial applications. Leveraging Fisher's extensive expertise in process control and measurement technologies, this transmitter combines advanced sensing capabilities with a rugged construction to ensure consistent performance even in challenging operational environments. The 56AMXN excels at converting level signals into precise electrical outputs, making it an essential component in processes where real-time level monitoring is critical for maintaining operational efficiency, ensuring safety, and optimizing resource utilization. Whether deployed in chemical storage tanks, water treatment facilities, or oil refineries, the Fisher 56AMXN stands out for its exceptional accuracy, durability, and seamless integration with various industrial control systems. Its compact design and flexible mounting options make it suitable for both new installations and retrofitting existing systems.
Technical Specifications
|
Parameter
|
Value
|
|
Product Model
|
56AMXN
|
|
Product Type
|
Industrial Level Transmitter
|
|
Measurement Range
|
0 - 30 meters
|
|
Output Signal
|
4 - 20 mA DC with HART
|
|
Power Supply
|
12 - 30 VDC
|
|
Accuracy
|
±0.2% of full scale
|
|
Operating Temperature Range
|
-40°C to 80°C
|
|
Protection Rating
|
IP66
|
|
Mounting Type
|
Flange mount, threaded mount
|
Key Features and Benefits
High Measurement Accuracy
The Fisher 56AMXN offers an impressive accuracy of ±0.2% of full scale, ensuring precise level measurement even in dynamic process conditions. This level of accuracy is crucial in industries such as chemical processing, where precise level control directly impacts product quality and process efficiency. The transmitter's advanced sensing technology minimizes drift over time, reducing the need for frequent recalibration and ensuring long-term reliable performance.
Versatile Measurement Range
With a measurement range of 0 - 30 meters, the 56AMXN can handle a wide variety of level measurement tasks, from small storage tanks to large industrial vessels. This versatility makes it suitable for diverse applications, including water treatment plants, oil and gas storage facilities, and food and beverage processing, eliminating the need for multiple transmitters for different tank sizes.
Wide Operating Temperature Range
The
Fisher 56AMXN operates efficiently within a temperature range of -40°C to 80°C, making it suitable for use in extreme environmental conditions. It can perform reliably in cold storage facilities as well as in high-temperature industrial environments, such as refineries and power plants. This wide temperature tolerance reduces the need for additional temperature protection measures, simplifying installation and reducing costs.
Robust Environmental Protection
Featuring an IP66 protection rating, the 56AMXN is dust-tight and resistant to high-pressure water jets, ensuring reliable operation in harsh industrial environments. This robust construction protects the transmitter from moisture, dust, and other contaminants, extending its service life and minimizing maintenance requirements. It is well-suited for outdoor installations and areas with high levels of dust or water exposure.
Seamless Integration with Control Systems
The Fisher 56AMXN is equipped with a 4 - 20 mA DC output signal with HART communication, enabling easy integration with standard industrial control systems, PLCs, and DCSs. The HART protocol allows for remote monitoring, configuration, and diagnostics, enhancing operational efficiency and reducing the need for on-site visits. Its flexible mounting options (flange mount and threaded mount) simplify installation in various tank and vessel configurations.
Related Models
- 56AMXP – A variant with a shorter measurement range (0 - 15 meters), ideal for smaller tanks and vessels, offering the same accuracy and reliability as the 56AMXN.
- 56AMXR – A model with an extended measurement range (0 - 50 meters), suitable for larger industrial applications requiring longer distance level measurement.
- 56AMXS – A sanitary-grade version designed for food, pharmaceutical, and biotech applications, featuring a smooth surface and easy cleaning to meet strict hygiene standards.
- Fisher 56AMXT – A transmitter with enhanced explosion-proof capabilities, certified for use in hazardous areas, making it suitable for oil and gas facilities with potentially explosive atmospheres.
- Fisher 475 Field Communicator – A companion device that works seamlessly with the 56AMXN for on-site configuration, calibration, and diagnostics, simplifying maintenance and troubleshooting.
As a trusted distributor, we are committed to providing excellent pre-sales and after-sales service, including a one-year warranty for the Fisher 56AMXN. Our team of experts has in-depth knowledge of industrial control systems and can provide professional advice on product selection, installation, and maintenance. If you need more information or cannot find the model you require, please contact us immediately. The 56AMXN is widely used in process industries for level monitoring in tanks and vessels, discrete manufacturing for inventory control, and infrastructure projects such as water supply and wastewater treatment systems.
