Brand/Manufacturer: Invensys
Dimensions: 6.2 cm x 42 cm x 17.7 cm
Weight: 2.32 kg
Country of origin: USA
Description: Invensys 9853-610 terminal panel
Current output, basic, 8 pts
The terminal panel 9853-610 is compatible with 4-20mA output modules and HART emulation
Output interface module. Each panel has:
• 8 current output terminals (OUT)
• 8 current return terminals (RTN)
• Used to connect redundant 24 VDC power supplies
The terminal characteristic specifications
Voltage 24 VDC, nominal value (Max range 20-28 VDC)
Current 20 mA Static current, Vsupply = 24 V, Vin = 0, RL = 0, Is
= 4 mA
Input impedance 1 MW differential mode
850 kΩ common mode
Input voltage range: 4-20 mA Output 0-20 V
Maximum input voltage, any
One terminal is related to the power supply
