Product Overview
The AMAT 0090-00224 is a high-reliability vacuum valve, specifically engineered to meet the stringent demands of semiconductor manufacturing and other high-vacuum industrial applications. This valve integrates precision engineering with durable materials, making it a critical component for controlling the flow of gases in vacuum systems.
The 0090-00224 is designed to provide tight shutoff and precise flow regulation in high-vacuum environments, ensuring optimal performance of vacuum chambers and processing tools. Whether deployed in semiconductor wafer fabrication facilities, thin-film deposition systems, or research laboratories requiring ultra-high vacuum conditions, the 0090-00224 delivers consistent and reliable operation. Its ability to maintain vacuum integrity even under repeated cycling, combined with its resistance to corrosive process gases, makes the 0090-00224 a trusted choice for engineers and operators in high-tech manufacturing.
Hainan Jinlin Mechanical & Electrical, as a reputable distributor of industrial control products, is proud to offer the AMAT 0090-00224. Guided by the "Customer First, Forge Ahead" business philosophy, we are dedicated to providing top-notch customer service to meet your specific requirements.
Technical Specifications
|
Parameter
|
Value
|
|
Product Model
|
0090-00224
|
|
Manufacturer
|
AMAT
|
|
Product Type
|
Vacuum Valve
|
|
Valve Type
|
Pneumatically Actuated Gate Valve
|
|
Nominal Size
|
2 inches
|
|
Operating Pressure Range
|
1x10^-9 Torr to 1 atm
|
|
Operating Temperature
|
-20°C to 150°C
|
|
Body Material
|
316L Stainless Steel
|
|
Seal Material
|
Viton®
|
Key Features and Benefits
Ultra-High Vacuum Compatibility
The 0090-00224 is designed to operate in ultra-high vacuum (UHV) environments down to 1x10^-9 Torr, ensuring minimal outgassing and maintaining the purity of process gases. This is crucial in semiconductor manufacturing, where even trace contaminants can compromise wafer quality. Its tight sealing capability prevents leaks, preserving vacuum integrity and reducing downtime associated with vacuum loss.
Corrosion Resistance
Constructed from 316L stainless steel, the
0090-00224 offers excellent resistance to corrosive process gases commonly used in semiconductor fabrication, such as chlorine and fluorine-based gases. The Viton® seals further enhance chemical compatibility, extending the valve's service life and reducing maintenance requirements in aggressive environments.
Precise and Reliable Actuation
Equipped with a pneumatically actuated mechanism, the 0090-00224 provides fast and repeatable opening/closing cycles, ensuring precise control over gas flow. This reliability is essential in automated manufacturing processes, where consistent valve performance directly impacts process uniformity and product yield. The actuation system is designed for long-term durability, withstanding millions of cycles without degradation.
Compact Design for System Integration
The 0090-00224 features a compact form factor that allows for easy integration into crowded vacuum system layouts. Its 2-inch nominal size makes it compatible with standard vacuum piping, simplifying installation and retrofitting into existing systems. The valve's design minimizes dead volume, reducing gas retention and improving process efficiency.
High-Temperature Operation
With an operating temperature range of -20°C to 150°C, the 0090-00224 can withstand the thermal variations encountered in various high-vacuum processes, including annealing and deposition steps. This temperature tolerance ensures stable performance across a wide range of manufacturing conditions, enhancing its versatility in complex production lines.
Related Models
- 0090-00223 – Similar to the 0090-00224 but with a 1.5-inch nominal size, suitable for smaller vacuum system pathways.
- 0090-00225 – A larger variant with a 3-inch nominal size, designed for higher gas flow rates than the 0090-00224.
- 0090-00226 – Features metal seals instead of Viton® for higher temperature resistance (up to 300°C), ideal for extreme thermal processes compared to the 0090-00224.
- 0090-00227 – Electrically actuated version of the 0090-00224, offering precise digital control for applications requiring automated sequencing.
- 0090-00228 – Angle valve configuration, providing flexibility in vacuum system plumbing compared to the straight-through design of the 0090-00224.
As a certified partner of industry leaders, we provide key components for various application areas. In the semiconductor industry, the 0090-00224 is widely used in ion implantation systems, plasma etching tools, and chemical vapor deposition (CVD) reactors, ensuring precise gas control during wafer processing. In research and development, it supports advanced materials science experiments requiring high-vacuum conditions.
We offer a one-year warranty for the 0090-00224 to ensure your peace of mind. Our professional pre-sales and after-sales service teams are always available to assist you with any inquiries or support needs. If you cannot find the model you require, please contact us immediately.
