Product Overview
The SCXI-1130 is a high-performance analog input module designed for use in National Instruments' SCXI (Signal Conditioning eXtensions for Instrumentation) systems, delivering precise signal conditioning and data acquisition for a wide range of industrial and laboratory applications. As a critical component in measurement setups, the SCXI-1130 excels at amplifying, isolating, and filtering low-level analog signals—such as those from sensors monitoring temperature, pressure, or strain—ensuring accurate data capture even in noisy environments.
Core features of the SCXI-1130 include high gain accuracy, excellent noise rejection, and compatibility with a variety of transducers, making it versatile for industries like automotive testing, aerospace research, and process control. Its modular design allows seamless integration with NI data acquisition hardware, simplifying system expansion and customization. With robust construction and adherence to strict quality standards, the SCXI-1130 provides reliable performance in both benchtop and industrial settings, ensuring consistent results for critical measurements.
Hainan Jinlin Mechanical & Electrical is a distributor of industrial control products, specializing in a wide range of brands. We possess extensive industry knowledge and market insights. Adhering to the "Customer First, Forge Ahead" business philosophy, we provide high-quality customer service. We're here for you, dedicated to meeting your needs!
Technical Specifications
|
Parameter
|
Value
|
|
Product Model
|
|
|
Manufacturer
|
NI
|
|
Product Type
|
Analog Input Signal Conditioning Module
|
|
Input Channels
|
8 differential channels
|
|
Gain Options
|
1, 10, 100, 1000
|
|
Input Range (at Gain 1)
|
±10 V
|
|
Operating Temperature
|
0°C to 55°C
|
|
Isolation
|
Channel-to-channel isolation (250 Vrms)
|
|
Power Requirements
|
5 VDC (200 mA), ±15 VDC (50 mA)
|
|
Dimensions
|
16.5 cm x 10.2 cm x 3.8 cm
|
Key Features and Benefits
Precise Signal Conditioning
The
SCXI-1130 offers selectable gain settings (1, 10, 100, 1000) to amplify weak signals from sensors, ensuring that even small variations in input are accurately captured. This precision is crucial for applications like material testing, where subtle changes in strain or pressure must be measured with high fidelity.
Superior Noise Rejection
Equipped with advanced filtering and isolation technologies, the SCXI-1130 minimizes the impact of electromagnetic interference (EMI) and radio-frequency interference (RFI) common in industrial environments. Channel-to-channel isolation (250 Vrms) prevents cross-talk between signals, maintaining data integrity in multi-sensor setups.
Broad Compatibility
Designed to work seamlessly with NI's SCXI chassis and data acquisition boards (such as PCIe-6363), the SCXI-1130 integrates easily into existing measurement systems. It supports a wide range of transducers, including thermocouples, strain gauges, and pressure sensors, making it a flexible solution for diverse applications.
Easy Configuration
The module can be configured via NI's LabVIEW or Measurement & Automation Explorer (MAX) software, allowing users to quickly set gain, filtering, and sampling parameters without manual hardware adjustments. This reduces setup time and ensures consistent configuration across multiple modules.
Durable Design
Built to withstand the rigors of industrial use, the SCXI-1130 features a rugged enclosure and stable performance over its operating temperature range (0°C to 55°C). This durability ensures long-term reliability in both factory floors and laboratory environments.
We stand behind the
SCXI-1130 with a one-year warranty, supported by our team of technical experts. From pre-sales system design to post-installation support, we provide guidance to help you maximize the module's performance in your specific application.
Related Models
- SCXI-1131 – 16-channel analog input module, offering expanded channel count compared to the SCXI-1130 for larger-scale systems.
- SCXI-1121 – Thermocouple input module, optimized for temperature measurements and compatible with the SCXI-1130 in mixed-signal setups.
- SCXI-1161 – Digital input/output module, ideal for pairing with the SCXI-1130 to add control capabilities to measurement systems.
- SCXI-1321 – Terminal block accessory, provides secure sensor connections for the SCXI-1130.
- SCXI-1130-SE – Single-ended version of the SCXI-1130, suitable for applications where differential input is not required.
- SCXI-1000 – 13-slot SCXI chassis, designed to house the SCXI-1130 and other SCXI modules in a compact rack-mount system.
- SCXI-1132 – High-speed analog input module, offering faster sampling rates than the SCXI-1130 for dynamic signal measurements.
