| Product Model | BENTLY 3500/22M 146031-01 |
| Manufacturer | Bently Nevada |
| Product Type | Vibration / Proximity Transducer |
| Measurement Range | ±50 mils (peak-to-peak) |
The BENTLY 3500/22M 146031-01 is a high-precision vibration monitoring transducer designed for critical rotating machinery applications. Manufactured by Bently Nevada, a global leader in condition monitoring and machinery protection systems, the BENTLY 3500/22M 146031-01 ensures reliable measurement of vibration and proximity signals, helping to prevent unexpected equipment failures and optimize maintenance schedules.
This transducer is widely used in turbines, compressors, motors, and generators across power generation, petrochemical, and industrial process plants. The BENTLY 3500/22M 146031-01 delivers accurate displacement measurements with high sensitivity and fast response time, providing essential data for real-time machinery diagnostics and predictive maintenance programs. Its rugged design allows operation in harsh environments, including high temperature, vibration, and electrical noise conditions.
Hainan Jinlin Mechanical & Electrical provides professional pre-sales consultation, technical support, and after-sales service for the BENTLY 3500/22M 146031-01, backed by a one-year warranty to ensure reliable operation and customer satisfaction.
| Parameter | Value |
|---|---|
| Product Model | BENTLY 3500/22M 146031-01 |
| Manufacturer | Bently Nevada |
| Product Type | Vibration / Proximity Transducer |
| Measurement Range | ±50 mils (peak-to-peak) |
| Operating Temperature | -40°C to +120°C |
| Output Signal | 4–20 mA / 1–10 V (depending on configuration) |
| Mounting | Flanged / Threaded |
| IP Rating | IP65 |
High-Precision Vibration Monitoring
The BENTLY 3500/22M 146031-01 provides highly accurate displacement and vibration measurements, enabling early detection of machinery imbalance, misalignment, and bearing defects.
Rugged and Reliable Construction
Engineered for harsh industrial conditions, this transducer offers resistance to high temperatures, vibration, and electromagnetic interference, ensuring stable and long-term operation.
Real-Time Diagnostics
With fast signal response and precise measurement capabilities, the BENTLY 3500/22M 146031-01 enables real-time condition monitoring and predictive maintenance, reducing unplanned downtime and maintenance costs.
Seamless System Integration
The transducer is fully compatible with the Bently Nevada 3500 Series Monitoring System and other standard industrial monitoring systems, allowing straightforward installation and network integration.
Ease of Maintenance
The modular design allows for quick replacement and minimal downtime during maintenance activities, ensuring continuous protection of critical machinery.
Professional Support and Warranty
Hainan Jinlin Mechanical & Electrical provides expert pre-sales consultation, technical guidance, and a one-year warranty, ensuring customer confidence and reliable operation.
3500/22M 146031-02 – Upgraded version with extended temperature range.
3500/22M 146030-01 – Previous generation module with standard sensitivity.
3500/22M 146032-01 – High-speed variant optimized for rapid-response monitoring.
3500/22M 146033-01 – Companion transducer for redundant monitoring systems.
3500/33M 146034-01 – Extended measurement range module for heavy machinery.
3500/22M 146031-03 – Enhanced environmental protection variant for extreme conditions.
