Product Overview
The HONEYWELL CC-GDOL11 is a rugged 16-channel digital output module engineered exclusively for Honeywell’s Experion PKS (Process Knowledge System) and ControlEdge DCS platforms. Designed to deliver high-power control signals to industrial actuators—such as heavy-duty solenoid valves, motor starters, and large-scale alarm systems—the HONEYWELL CC-GDOL11 acts as a critical bridge between central control systems and field equipment in high-demand environments. Its robust construction withstands extreme industrial conditions, including wide temperature fluctuations (-10°C to +60°C), high electrical noise, and mechanical vibration, making it a staple in petrochemical refineries, power plant turbine rooms, and large-scale chemical processing facilities. The HONEYWELL CC-GDOL11 adheres to global safety and industrial standards (IEC 61000-6-2, UL 508, CSA C22.2 No. 14) and integrates advanced fault-detection tools to minimize unplanned downtime, ensuring reliable performance in mission-critical applications where high-power, synchronized control is non-negotiable. Whether used for new DCS installations, legacy system retrofits, or high-load industrial processes, the HONEYWELL CC-GDOL11 delivers scalable, durable digital output functionality.
Hainan Jinlin Mechanical & Electrical is a distributor of industrial control products, specializing in a wide range of brands. We possess extensive industry knowledge and market insights. Adhering to the "Customer First, Forge Ahead" business philosophy, we provide high-quality customer service. We're here for you, dedicated to meeting your needs!
Technical Specifications
|
Parameter
|
Value
|
|
Product Model
|
CC-GDOL11
|
|
Manufacturer
|
Honeywell
|
|
Product Type
|
16-Channel Industrial Digital Output Module (Relay-Based)
|
|
Output Channels
|
16 independent channels; SPDT (Single Pole Double Throw) relay output
|
|
Per-Channel Load Capacity
|
5A @ 250V AC / 5A @ 30V DC (resistive load)
|
|
Output Response Time
|
≤5ms (actuation); ≤3ms (de-actuation)
|
|
Operating Temperature
|
-10°C to +60°C (14°F to +140°F)
|
|
Storage Temperature
|
-40°C to +85°C (-40°F to +185°F)
|
|
Power Supply
|
24V DC (18-32V DC), 12W max consumption
|
|
Communication Protocol
|
Honeywell FLEXBUS (native to Experion PKS/ControlEdge); Modbus TCP/IP (via system gateway)
|
|
Isolation
|
2.5kVrms (channel-to-channel, channel-to-power supply)
|
|
Mounting Type
|
Backplane mounting (Honeywell Experion PKS/ControlEdge racks) / DIN rail (35mm standard, with adapter)
|
|
IP Rating
|
IP20 (front panel); IP40 (when installed in Honeywell-certified control cabinets)
|
Key Features and Benefits
The HONEYWELL CC-GDOL11 leverages Honeywell’s decades of industrial control expertise to address the demand for high-power, reliable output control, offering unique advantages for heavy-duty industrial applications.
Native Integration with Honeywell DCS Platforms
Optimized for Honeywell’s Experion PKS and ControlEdge DCS, the HONEYWELL CC-GDOL11 connects directly to system control engines (C300, C500, ControlEdge EC900) without third-party adapters. Configuration via Honeywell’s Control Builder or Edge Control Designer software streamlines setup—for example, mapping channels to refinery crude oil valve actuators or power plant boiler feed pump starters—ensuring synchronized data flow between the module and central HMI. This eliminates integration delays and reduces the risk of protocol mismatches common in mixed-vendor systems.
16-Channel High-Power Relay Output
Each of the HONEYWELL CC-GDOL11’s 16 channels features an SPDT relay with a 5A load capacity (250V AC/30V DC), making it ideal for controlling high-power equipment that smaller transistor-based modules cannot handle. For instance, in a steel mill, the module can simultaneously trigger 16 hydraulic press solenoids (each requiring 3A @ 24V DC) or in a power plant, control 16 turbine cooling fan starters—all without the need for external power amplifiers, simplifying system design and lowering hardware costs.
Industrial-Grade Durability
Built to Honeywell’s strict industrial standards, the HONEYWELL CC-GDOL11 operates reliably in temperatures ranging from -10°C to +60°C and resists mechanical vibration (tested to IEC 60068-2-6) and electrical interference (EMI/RFI shielding per EN 61000-6-3). Its rugged relay contacts are rated for 100,000+ mechanical operations, ensuring a long service life (typically 12+ years) in high-cycle applications—critical for industries where module replacement is costly and disruptive.
Advanced Fault Detection and Diagnostics
The
HONEYWELL CC-GDOL11 includes comprehensive diagnostic features: channel-level relay weld detection, overcurrent protection, and power supply monitoring. Faults (e.g., a stuck relay or shorted output) are instantly logged in the DCS with timestamps and error codes, while front-panel LED indicators (green = active, red = fault, amber = warning) provide on-site technicians with real-time status visibility. For example, if a valve actuator shorts and overloads a channel, the module triggers an alert within 2ms, allowing maintenance teams to isolate the issue before it damages other equipment.
Flexible Mounting Options
The HONEYWELL CC-GDOL11 supports both backplane mounting (for seamless integration into Honeywell Experion/ControlEdge racks) and DIN rail mounting (via optional adapter) for custom control cabinets. This flexibility makes it suitable for both new DCS installations (where backplane integration is preferred) and legacy system retrofits (where DIN rail space is limited), ensuring compatibility with diverse infrastructure.
Related Models
- HONEYWELL CC-GDOL08 – 8-channel compact variant of HONEYWELL CC-GDOL11, ideal for small-scale high-power applications (e.g., HVAC chiller control, packaging line motor starters).
- HONEYWELL CC-GDOL24 – 24-channel upgraded version of HONEYWELL CC-GDOL11, designed for large facilities (e.g., petrochemical complexes) requiring extensive high-power output control.
- HONEYWELL CC-GDOT11 – Transistor-based counterpart of HONEYWELL CC-GDOL11 (16 channels, 1A @ 24V DC), optimized for low-power devices (e.g., indicator lights, small solenoids).
- HONEYWELL CC-GDOL11-EX – Explosion-proof variant of HONEYWELL CC-GDOL11, certified to ATEX Zone 2/CSA Class I Div 2 for hazardous areas (e.g., gas processing plants, oil wellheads).
- HONEYWELL CC-PWR-24V-15A – Dedicated power supply module optimized for HONEYWELL CC-GDOL11, delivering stable 24V DC to power high-load relays and associated actuators.
- HONEYWELL CC-COM-GW-TCP – Gateway module extending HONEYWELL CC-GDOL11’s connectivity to non-Honeywell PLCs (e.g., Siemens S7-1500) via Modbus TCP/IP.
- HONEYWELL FC-SDI-1624 – 16-channel digital input module, complementary to HONEYWELL CC-GDOL11 for synchronized monitoring (e.g., sensor status) and control (e.g., actuator triggering).
- HONEYWELL CC-GDOL11-H – High-temperature variant of HONEYWELL CC-GDOL11, rated for -20°C to +70°C for extreme environments (e.g., desert solar plants, foundries).
Company Expertise & Application Areas
As a certified Honeywell partner and distributor of leading industrial control brands (Emerson, ABB, TRICONEX), we specialize in delivering Honeywell CC-series components for critical sectors:
- Process Industries: In petrochemical refineries and chemical plants, the HONEYWELL CC-GDOL11 controls high-power valves (e.g., crude oil pipeline valves) and batch reactor agitators, ensuring compliance with safety standards (IEC 61511) and optimizing process efficiency.
- Power Generation: For thermal, nuclear, and renewable power plants, the module triggers turbine auxiliary systems (e.g., lubrication pump starters) and cooling fan motors, enabling real-time control via Experion PKS and reducing the risk of equipment overheating.
- Heavy Manufacturing: In steel mills and automotive assembly plants, the HONEYWELL CC-GDOL11 operates hydraulic presses, conveyor belt motors, and paint booth ventilation systems—handling the high-power demands of industrial machinery with consistent reliability.
We prioritize end-to-end support for Honeywell products: our pre-sales team provides DCS system design consultations to tailor HONEYWELL CC-GDOL11 to your output control needs, while our after-sales team offers on-site commissioning and troubleshooting. All units include a one-year warranty (extendable to 3 years) and access to Honeywell’s global technical support network. If you require additional Honeywell modules or custom configuration, contact us immediately for tailored solutions.
