Product Overview
The GE DS3800HCVA1J1H is a rugged high-voltage power supply module engineered to deliver reliable power to critical industrial control components, serving as a “high-voltage energy hub” for GE’s Mark VIe DCS (Distributed Control System) and turbine control systems—widely used in power generation (gas/steam turbine control), heavy industrial processing, and petrochemical refining. This module converts low-voltage input (common in DCS cabinets) into regulated high-voltage output to power energy-intensive components like turbine excitation circuits, high-power I/O modules, or precision sensors—making it indispensable for power energy industries, which align with Hainan Jinlin’s focus on power energy safety interlock control and DCS system stability. What sets the GE DS3800HCVA1J1H apart is its exceptional output voltage regulation (±2% tolerance) and robust overvoltage/overcurrent protection, ensuring safe, consistent power delivery even in harsh environments with voltage fluctuations or mechanical vibration (common in power plant turbine halls). Additionally, its seamless compatibility with GE’s Mark VIe ecosystem—including the GE IS420UCSBH3A control module (to supply stable power for its redundant processing core) and Mark VIe I/O modules—ensures easy integration into new or retrofitted automation setups. Whether deployed to power turbine control circuits in a coal-fired power plant or high-power sensors in a petrochemical reactor, the GE DS3800HCVA1J1H delivers the high-voltage reliability and system synergy that Hainan Jinlin’s clients depend on to keep mission-critical automation systems running safely and continuously.
Technical Specifications
|
Parameter
|
Value
|
|
Product Model
|
GE DS3800HCVA1J1H
|
|
Manufacturer
|
GE Automation (Industrial Power Supply Series)
|
|
Product Type
|
High-Voltage Regulated Power Supply Module
|
|
Compatible Systems
|
GE Mark VIe DCS, GE turbine control systems
|
|
Input Voltage
|
24 V DC (20-28 V DC wide range, compatible with DCS cabinet power)
|
|
Output Voltage
|
150 V DC (regulated; ±2% tolerance at full load)
|
|
Maximum Output Current
|
2 A (continuous); 3 A (peak, 10-second duration)
|
|
Power Conversion Efficiency
|
≥88% at full load (minimizes heat generation)
|
|
Operating Temperature
|
0°C to +55°C (32°F to +131°F)
|
|
Dimensions (W×H×D)
|
127 mm × 178 mm × 254 mm (5.0×7.0×10.0 in)
|
|
Mounting Type
|
Rack-mounted (GE Mark VIe standard chassis; compatible with GE IS420UCSBH3A’s rack)
|
|
Protection Rating
|
IP20 (front panel); conformal coating (optional for dusty/humid environments)
|
|
Protection Functions
|
Overvoltage protection (180 V DC cutoff), overcurrent protection (3.5 A trip), over-temperature protection (70°C shutdown)
|
|
LED Indicators
|
Power ON (green), Output OK (blue), Fault (red)
|
|
Cooling Method
|
Passive heat dissipation (enhanced with aluminum heat sink)
|
|
Compliance Standards
|
IEC 61010-1 (industrial power supplies), UL 508, CE, RoHS
|
Key Features and Benefits
The GE DS3800HCVA1J1H excels in high-voltage power delivery for industrial automation due to its precision regulation, robust protection, and seamless GE ecosystem integration—all enhanced by Hainan Jinlin’s professional services. Its primary advantage is the regulated 150 V DC output with ±2% tolerance: this stability is critical for powering components like the GE IS420UCSBH3A’s auxiliary circuits (which require consistent voltage to maintain redundant processing) or turbine excitation sensors (where voltage fluctuations could cause speed control errors). In power plants, this precision prevents unplanned turbine trips—avoiding production losses that can cost hundreds of thousands of dollars per hour, aligning with our company’s commitment to power energy operational continuity.
Another critical strength is the GE DS3800HCVA1J1H’s multi-layer protection system. Overvoltage protection cuts off output if voltage exceeds 180 V DC, shielding sensitive control modules (like the GE IS420UCSBH3A) from damage caused by grid surges. Over-temperature protection uses a built-in thermal sensor to shut down the module if it exceeds 70°C—preventing component burnout in high-heat environments (e.g., turbine hall cabinets). Additionally, its passive cooling design eliminates the need for fans, reducing maintenance needs (no fan replacement) and avoiding dust accumulation (a common issue in power plants).
Hainan Jinlin amplifies the value of the
GE DS3800HCVA1J1H through end-to-end support: our pre-sales engineers help clients verify compatibility (e.g., ensuring it pairs with the
GE IS420UCSBH3A to power its redundant core) and calculate power requirements for turbine control setups. Post-purchase, we provide on-site installation guidance (including wiring to Mark VIe chassis) and 24/7 technical troubleshooting—all backed by a one-year after-sale guarantee. For custom needs (e.g., adding conformal coating for coastal power plants), our team coordinates with GE to deliver tailored configurations. Connect with us via [WhatsApp](
https://wa.me/+86 19389860630) (opens in a new window) for immediate pre-sales advice on high-voltage power system design.
Related Models
- GE DS3800HCVA1J2H – Higher-output variant of the GE DS3800HCVA1J1H, delivering 200 V DC output (ideal for powering larger turbine excitation circuits or multi-module Mark VIe racks).
- GE DS3800HCVA1J0H – Lower-output variant, providing 120 V DC output (suitable for powering smaller I/O banks or sensors paired with the GE IS420UCSBH3A).
- GE DS3800HCVA2J1H – Redundant power supply variant, supporting 1+1 hot standby (automatically switching to backup if the primary GE DS3800HCVA1J1H fails—critical for nuclear power plant safety systems).
- GE DS3800HCVA1J3H – Wide-temperature variant, operating from -20°C to +65°C (-4°F to +149°F) for harsh environments like offshore wind turbine control cabinets.
- GE DS3800HCVB1J1H – Dual-output variant, adding a 24 V DC auxiliary output to the GE DS3800HCVA1J1H’s 150 V DC main output (to power both high-voltage components and low-voltage sensors).
- GE DS3800HCVA1J4H – High-efficiency variant (≥92% efficiency) of the GE DS3800HCVA1J1H, reducing energy consumption for large-scale power plants with multiple Mark VIe systems.
- GE DS3800HCVA1J5H – Safety-certified variant, meeting IEC 61508 SIL 2 standards (compatible with the GE IS420UCSBH3A in safety-critical turbine shutdown circuits).
