EL3040 is a double-layer detector and optocoupler, which has the advantages of good selectivity and low detection limit value. In addition, it also has corrosion-resistant gas path, sample gas chamber can be cleaned, electrical and physical characteristics, airtight isolation, can be purged, protection class IP65 and other features. The instrument has a heated type option for EEx (p) explosion protection and is suitable for zones 1 and 2.
The EL3040 weighs approximately 15kg (1 IR channel) or 21kg (2 IR channels), and the power consumption is approximately 40VA for a single channel and 70VA for a dual channel. Power supply is 100-240VAC±10% 48-63HZ, linear error is ±0.5%FS, response time is <3 seconds, analog output is 0/2/4-20mA maximum load 750Ω.
In addition, the EL3040 has a measurement drift of ±1%FS/ week, a maximum range depending on the application, a minimum range of CO: 0-10ppm CO2:0-5ppm, and a measurement range of 4 ranges with automatic range switching.
The EL3040 is an analytical instrument used to continuously measure the concentration of a single component in a gas or steam, but cannot measure combustible gases/air, or mixtures of gases and oxygen.
The EL3040 is a gas analyzer with the following features and benefits:
Efficient measurement: Advanced measurement technology can quickly and accurately measure the gas concentration to ensure the accuracy and reliability of the measurement results.
Multi-functional integration: The EL3040 gas analyzer integrates a variety of measurement modules, which can simultaneously measure a variety of gas concentrations to meet the needs of different application scenarios.
Easy to operate: The analyzer has a user-friendly interface and operation mode for easy configuration, debugging and troubleshooting operations.
High reliability: The use of high-quality materials and manufacturing processes to ensure the reliability and durability of the analyzer, reducing failure and maintenance costs.
However, the EL3040 also has some drawbacks:
High cost: Due to its use of advanced measurement technology and high-quality materials, the manufacturing cost is high, which may increase the cost of the entire system.
Regular maintenance required: In order to maintain its accuracy and reliability, regular maintenance and calibration are required, which may require additional cost and time.
Overall, the EL3040 is a powerful and reliable gas analyzer with a wide range of applications. Although it is expensive and requires regular maintenance, its powerful function and stability make it still important in the field of gas analysis.
