EPSCPE100-ABAC is a high-performance module with the following features:
The bandwidth is 100 MHz and the storage depth is 1M sampling points (single channel) or 500K sampling points (dual channel).
Supports the dual-channel plus external trigger function. The real-time sampling rate is 1 GSa/s (single-channel) or 500MSa/s (dual-channel), the equivalent sampling rate is 25 GSa/s, and the rise time is 1.2 ns.
The input impedance is 1 MΩ || 15 pF,50 Ω, and the time base range is 2 ns/div to 50 s/div.
The bandwidth of Lisayu graphics is 50 MHz and the phase difference is ± 3°.
Supports multiple trigger modes, including edge, video, pulse width, etc.
EPSCPE100-ABAC is a powerful module with specific functions and application areas as follows:
Features:
High performance: EPSCPE100-ABAC uses advanced signal processing technology, with high bandwidth, high sampling rate and low noise characteristics, to provide high-quality signal acquisition and measurement.
Multi-channel: Supports multi-channel input, can collect multiple signals at the same time, suitable for multi-channel signal processing and measurement application scenarios.
Multiple trigger modes: EPSCPE100-ABAC supports multiple trigger modes, such as edge trigger, video trigger, pulse width trigger, etc., which is convenient for users to select according to actual requirements.
Flexible configuration: EPSCPE100-ABAC has flexible configuration options. Users can configure different parameters, such as sampling rate and trigger source, to meet specific application requirements.
Application field:
EPSCPE100-ABAC is widely used in various fields requiring high-performance signal acquisition and measurement, such as communications, radar, electronic countermeasures, audio processing, vibration analysis, etc. It can be used as an important part of various test and measurement equipment and automatic control system for collecting, analyzing, processing and output various signals and data. The power and flexibility of EPSCPE100-ABAC enable it to perform well in a variety of complex and demanding application scenarios, providing a reliable solution for a variety of signal processing and measurement tasks.
In summary, the EPSCPE100-ABAC is a high-performance, multi-channel signal acquisition module with multiple trigger modes and flexible configuration options for a variety of applications requiring high-performance signal acquisition and measurement.
