Product Overview
The FC-PSU-240516 is a high-reliability industrial power supply unit engineered to deliver consistent, regulated DC power to critical automation components—including machinery protection modules, PLCs, and sensor networks—in harsh industrial environments. Designed with a focus on stability and durability, the FC-PSU-240516 features wide input voltage compatibility, built-in surge protection, and high efficiency, ensuring uninterrupted power delivery even during voltage fluctuations or transient events. Ideal for power generation, petrochemical, and manufacturing sectors, the FC-PSU-240516 is particularly well-suited for powering systems like Bently Nevada’s 3500 machinery protection modules (e.g., the 3500/33-01-00), where power interruptions could compromise equipment monitoring and safety. Its compact, rack-mountable design and user-friendly status indicators also simplify integration and maintenance, making it a cost-effective solution for both new installations and legacy system upgrades.
Hainan Jinlin Mechanical & Electrical is a distributor of industrial control products, specializing in a wide range of brands. We possess extensive industry knowledge and market insights. Adhering to the "Customer First, Forge Ahead" business philosophy, we provide high-quality customer service. We're here for you, dedicated to meeting your needs!
Technical Specifications
|
Parameter
|
Value
|
|
Product Model
|
FC-PSU-240516
|
|
Manufacturer
|
Industrial Power Solutions (Common for FC-PSU Series)
|
|
Product Type
|
Regulated Industrial DC Power Supply
|
|
Input Voltage Range
|
85-264 V AC (50/60 Hz)
|
|
Output Voltage
|
24 V DC (±0.5% regulation)
|
|
Output Current
|
16 A (continuous), 32 A (peak)
|
|
Efficiency
|
≥ 92% (at full load)
|
|
Operating Temperature
|
-20°C to +70°C (-4°F to +158°F)
|
|
IP Rating
|
IP21 (rack-mounted, dust/water spray protected)
|
|
Protection Features
|
Overcurrent, Overvoltage, Short-Circuit, Over-temperature
|
Key Features and Benefits
Wide Input Compatibility & Stable Output
The FC-PSU-240516 accepts a broad input voltage range (85-264 V AC), making it suitable for global industrial applications—from 110 V AC (North America) to 230 V AC (Europe/Asia). Its tight output regulation (±0.5% for 24 V DC) ensures consistent power delivery to sensitive components like the 3500/33-01-00 monitor module, preventing voltage spikes or drops that could corrupt sensor data or trigger false alarms. This stability is critical for 24/7 operations in power plants or refineries, where even minor power inconsistencies can disrupt critical monitoring systems.
High Efficiency & Energy Savings
With an efficiency rating of ≥92% at full load, the FC-PSU-240516 minimizes energy waste compared to standard power supplies (typically 85-88% efficient). This translates to lower electricity costs over the unit’s lifespan—especially in large-scale installations with multiple power supplies. Its low heat dissipation also reduces the need for additional cooling in control cabinets, lowering overall system maintenance costs.
Comprehensive Protection Mechanisms
The FC-PSU-240516 includes multi-layer protection features to safeguard both the power supply and connected equipment: overcurrent protection prevents damage from excessive load (e.g., a shorted sensor), overvoltage protection clamps voltage surges (common during grid fluctuations), and over-temperature protection shuts down the unit if internal temperatures exceed 70°C. These safeguards reduce equipment failure rates by up to 40% and extend the lifespan of downstream components like the 3500/33-01-00.
Rugged Design for Harsh Environments
Engineered for industrial durability, the
FC-PSU-240516 features a metal chassis and conformal-coated circuit boards that resist dust, humidity, and chemical vapors—common in petrochemical or offshore environments. Its operating temperature range of -20°C to +70°C ensures reliable performance in extreme conditions, from cold storage facilities to hot manufacturing floors. Unlike consumer-grade power supplies, it undergoes rigorous testing for shock (10 G) and vibration (5 G), making it suitable for mobile equipment or areas with mechanical stress.
User-Friendly Monitoring & Maintenance
The FC-PSU-240516 includes front-panel LED indicators for input power, output status, and fault conditions (e.g., over-temperature, short-circuit), allowing technicians to quickly diagnose issues without specialized tools. Its rack-mountable design (1U height) saves space in standard 19-inch control cabinets, while tool-free terminal blocks simplify wiring and replacement. For remote monitoring, optional communication modules (Modbus RTU/Ethernet) can be added to track output voltage, current, and temperature via a DCS or HMI—enhancing visibility into system health.
Related Models
- FC-PSU-240508 – Lower-current variant of the FC-PSU-240516 (8 A continuous output), ideal for small-scale setups (e.g., 1-2 3500/33-01-00 modules).
- FC-PSU-240520 – Higher-current upgrade (20 A continuous output), designed for large systems with multiple automation components.
- FC-PSU-120516 – 12 V DC output version of the FC-PSU-240516, suitable for low-voltage equipment (e.g., small sensors or microcontrollers).
- FC-PSU-240516-R – Redundant model, featuring two internal power supplies for 1+1 redundancy—critical for safety-critical systems (e.g., nuclear power plant monitoring).
- FC-PSU-240516-W – Wide-temperature variant (-40°C to +85°C), designed for extreme environments like desert oil fields or Arctic pipelines.
- FC-PSU-480516 – 48 V DC output model, compatible with high-voltage industrial equipment (e.g., large servo motors or heavy-duty sensors).
- FC-PSU-240516-P – Panel-mounted version (instead of rack-mounted), suitable for space-constrained cabinets or wall-mounted control systems.
Company Expertise & Warranty
As a certified partner of industry leaders such as Bently Nevada, Honeywell, and Mitsubishi Electric, we provide key components for process industries, discrete manufacturing, and infrastructure. Our pre-sales team offers technical consultations to ensure the FC-PSU-240516 matches your power requirements (e.g., load calculation for 3500 series modules), while our after-sales service includes on-site installation support, wiring verification, and troubleshooting. All products, including the FC-PSU-240516, come with a one-year warranty covering manufacturing defects and performance issues.
If you cannot find the model you need, please contact us immediately.
