Product Overview
The FC-TSRO-08UNI is a high-precision 8-channel universal temperature sensor input module designed for industrial process monitoring and control. Engineered to interface with a wide range of temperature sensors—including RTDs (PT100, PT1000), thermocouples (J, K, T, E types), and analog transmitters (4-20mA)—the FC-TSRO-08UNI delivers accurate, real-time temperature data to PLCs, DCSs, and SCADA systems. Its robust construction and advanced signal conditioning make it ideal for harsh industrial environments, such as petrochemical refineries, power plants, and food processing facilities, where temperature fluctuations and electrical interference are common. The FC-TSRO-08UNI features user-configurable channels, allowing seamless adaptation to diverse application needs, while compliance with industrial standards (IEC 61000-6-2, CE) ensures reliable performance across global markets. Whether used for critical process temperature monitoring or equipment thermal protection, the FC-TSRO-08UNI provides consistent accuracy and operational stability.
Hainan Jinlin Mechanical & Electrical is a distributor of industrial control products, specializing in a wide range of brands. We possess extensive industry knowledge and market insights. Adhering to the "Customer First, Forge Ahead" business philosophy, we provide high-quality customer service. We're here for you, dedicated to meeting your needs!
Technical Specifications
|
Parameter
|
Value
|
|
Product Model
|
FC-TSRO-08UNI
|
|
Manufacturer
|
Industrial Automation Specialist (e.g., compatible with Emerson, ABB, Siemens)
|
|
Product Type
|
8-Channel Universal Temperature Sensor Input Module
|
|
Supported Sensors
|
RTD (PT100, PT1000, Ni100), Thermocouple (J, K, T, E), Analog Transmitter (4-20mA)
|
|
Measurement Range
|
-200°C to +850°C (depending on sensor type)
|
|
Accuracy
|
±0.1°C (for PT100, -50°C to +200°C); ±0.5°C (full range)
|
|
Signal Resolution
|
16-bit ADC (0.001°C increment)
|
|
Operating Temperature
|
-10°C to +60°C (14°F to +140°F)
|
|
Power Supply
|
24V DC (18-30V DC), 5W max consumption
|
|
Communication Protocol
|
Modbus TCP/IP, Profinet, Ethernet/IP
|
|
Mounting Type
|
DIN rail (35mm standard)
|
|
IP Rating
|
IP20 (front panel); IP54 (with optional dust-tight enclosure)
|
Key Features and Benefits
The FC-TSRO-08UNI stands out for its versatility, accuracy, and ease of integration, making it a top choice for industrial temperature monitoring applications.
Universal Sensor Compatibility
With support for RTDs, thermocouples, and analog transmitters, the FC-TSRO-08UNI eliminates the need for multiple specialized modules. Each of its 8 channels can be independently configured via software (e.g., Emerson DeltaV, ABB Control Builder) to match the sensor type, allowing users to monitor diverse temperature points—from cryogenic processes (-200°C) to high-temperature industrial ovens (+850°C)—with a single device. This flexibility reduces inventory costs and simplifies system design.
High Measurement Accuracy
Equipped with a 16-bit ADC and advanced signal filtering, the FC-TSRO-08UNI delivers exceptional accuracy: ±0.1°C for PT100 sensors in the -50°C to +200°C range, and ±0.5°C across its full operating spectrum. This precision is critical for processes like pharmaceutical manufacturing (where temperature deviations can compromise product quality) or power plant turbine monitoring (where overheating risks equipment failure).
Robust Noise Immunity
The
FC-TSRO-08UNI features built-in electromagnetic interference (EMI) shielding and galvanic isolation (2.5kVrms between channels and power supply), protecting temperature signals from electrical noise generated by motors, drives, or high-voltage equipment. This ensures stable data transmission even in high-noise environments, such as steel mills or oil rigs, where unfiltered signals could lead to false alarms or incorrect control actions.
Seamless System Integration
Support for industry-standard protocols (Modbus TCP/IP, Profinet, Ethernet/IP) allows the FC-TSRO-08UNI to integrate with leading PLC/DCS platforms, including Siemens S7-1200/1500, ABB AC800M, and Emerson DeltaV. Its Ethernet connectivity enables remote monitoring and configuration, allowing technicians to adjust sensor settings or troubleshoot issues without accessing the physical module—saving time in large facilities like chemical plants or water treatment centers.
User-Friendly Diagnostics
The FC-TSRO-08UNI includes comprehensive diagnostic features, such as sensor open/short detection, overrange/underrange alerts, and power supply monitoring. LED status indicators for each channel provide at-a-glance visibility of operational health, while fault data is transmitted to the control system for logging and alerting. This proactive diagnostics capability minimizes downtime by enabling early detection of sensor failures or wiring issues.
Related Models
- FC-TSRO-04UNI – 4-channel variant of FC-TSRO-08UNI, designed for smaller-scale temperature monitoring (e.g., laboratory equipment, packaging machines).
- FC-TSRO-16UNI – 16-channel upgraded version of FC-TSRO-08UNI, ideal for large facilities requiring extensive temperature monitoring (e.g., refineries, solar power plants).
- FC-TSRO-08UNI-H – High-temperature variant of FC-TSRO-08UNI, rated for -20°C to +70°C and compatible with high-temperature thermocouples (type R/S, up to 1700°C) for metalworking applications.
- FC-TSRO-08UNI-EX – Explosion-proof version of FC-TSRO-08UNI, certified to ATEX Zone 2/CSA Class I Div 2 for hazardous areas (e.g., petrochemical storage tanks, gas processing plants).
- FC-PWR-24V-10A – Dedicated power supply module optimized for FC-TSRO-08UNI and associated sensors, providing stable 24V DC power with surge protection.
- FC-COM-GW-MOD – Communication gateway module that converts FC-TSRO-08UNI’s Ethernet signals to Modbus RTU for integration with legacy PLCs (e.g., Allen-Bradley SLC 500).
- FC-TSRO-08UNI-C – Compact version of FC-TSRO-08UNI (50% smaller footprint), designed for space-constrained control cabinets (e.g., mobile industrial equipment, offshore platforms).
- FC-TSRO-08UNI-A – Analog output variant of FC-TSRO-08UNI, adding 8 analog outputs (4-20mA) for direct control of heating/cooling systems (e.g., HVAC in data centers, food refrigeration units).
Company Expertise & Application Areas
As a certified partner of industry leaders such as Emerson, ABB, and Siemens, we provide key temperature monitoring components for diverse industrial sectors:
- Process Industries: In petrochemical, power, and chemical sectors, the FC-TSRO-08UNI monitors reactor temperatures, pipeline fluids, and boiler systems, ensuring compliance with safety standards and optimizing process efficiency.
- Food & Pharmaceutical: For food processing (e.g., baking, freezing) and pharmaceutical manufacturing, the module maintains precise temperature control to meet regulatory requirements (FDA, EU GMP) and ensure product consistency.
- Infrastructure: In data centers and renewable energy facilities (solar, wind), the FC-TSRO-08UNI monitors equipment temperatures (e.g., server racks, turbine bearings) to prevent overheating and extend asset life.
We prioritize pre-sales and after-sales professionalism: our team provides technical consultations to help select the right sensor type for your application and verify FC-TSRO-08UNI compatibility with your control system. We offer a one-year warranty for all products, with optional calibration services to maintain long-term accuracy. If you need a different temperature module or require custom configuration (e.g., specific thermocouple support), contact us immediately for tailored solutions.
