The SCXI - 1325 is a high - voltage terminal block that plays a crucial role in industrial signal connection and isolation scenarios. Engineered with precision, it is specifically designed to establish secure connections with the SCXI - 1124 analog output module. The SCXI - 1325 is a go - to solution for applications where high - voltage isolation and reliable signal transfer are of utmost importance. It simplifies the process of connecting and disconnecting signals from the user's system, offering a straightforward and user - friendly experience. With its advanced features, it caters to a wide range of industries, from manufacturing plants to research laboratories.
High - Voltage Isolation: The SCXI - 1325 provides an impressive 250 Vrms channel - to - ground and channel - to - channel isolation. This high - level isolation is vital in harsh industrial environments, effectively safeguarding equipment from electrical malfunctions and protecting operator safety. It ensures that signals are transmitted stably, minimizing interference and guaranteeing the accuracy and reliability of data transfer.
Powerful Wiring Capability: Equipped with 26 screw terminals, the SCXI - 1325 offers great flexibility in wiring. Two of these terminals are dedicated to connecting to the SCXI - 1124 chassis ground, while the remaining 24 are for signal connections to the six output channels on the SCXI - 1124 module. This setup allows users to easily interface multiple sensors or signal sources, making it suitable for complex test setups and data acquisition tasks.
Versatile Connectivity Options: Users can directly connect transducers at the front - mounted BNC connectors or the screw terminals. This flexibility enables the easy achievement of current or voltage output in each output channel of the SCXI - 1124. Whether dealing with simple or intricate sensor setups, the SCXI - 1325 can accommodate the connection requirements.
Isothermal Construction for Accuracy: To ensure high - accuracy signal conditioning, the SCXI - 1325 features an isothermal construction. This design helps in maintaining consistent performance under varying temperature conditions, which is particularly important in applications where precise measurements are required.
Wide - Range of Applications: The SCXI - 1325 finds applications in a diverse range of fields. In laboratory measurement, it provides the necessary isolation and connection options for delicate experiments. In automation control, it can be used to interface various control components. In test and measurement scenarios, its reliable signal handling capabilities are invaluable. It is also well - suited for monitoring and data acquisition systems, where accurate and stable signal transfer is essential.
Backed by a one - year warranty, the SCXI - 1325 comes with professional pre - sales support to help you choose the right setup for your application and responsive after - sales service in case of any issues.
- SCXI - 1324 – A high - voltage screw terminal block similar to the SCXI - 1325, but may have differences in the number of terminals or specific isolation characteristics, often used in scenarios where a slightly different configuration is required.
- SCXI - 1327 – A high - voltage attenuator terminal block. It can be used in conjunction with the SCXI - 1325 in applications where signal attenuation needs to be incorporated into the overall signal conditioning and connection setup.
- SCXI - 1124 – The analog output module with which the SCXI - 1325 is designed to be securely connected. They work in tandem to enable accurate signal output and connection in industrial systems.
- SCXI - 1000 – The chassis that the SCXI - 1325 can be integrated with. The SCXI - 1000 provides a framework for housing and powering multiple SCXI modules, including the SCXI - 1325, facilitating system - level integration.
