IBA-SM128V Product Description
Product Overview
The
IBA-SM128V is a high-performance signal conditioning module designed for precise industrial data acquisition and monitoring. As a key component in IBA’s range of automation solutions, this module is engineered to process and amplify analog signals from various sensors, ensuring accurate data transmission to control systems and data loggers. The
IBA-SM128V excels in converting weak or noisy sensor signals into stable, industry-standard outputs, making it an essential tool for applications such as process monitoring, machinery diagnostics, and quality control. Its compact design and versatile compatibility allow for seamless integration into existing industrial setups, while its robust construction ensures reliable operation in harsh environments. The
IBA-SM128V stands out as a critical link in maintaining data integrity across complex industrial systems.
Technical Specifications
|
Parameter
|
Value
|
|
Product Model
|
IBA-SM128V
|
|
Manufacturer
|
IBA
|
|
Product Type
|
Signal Conditioning Module
|
|
Input Channels
|
16 differential analog inputs
|
|
Input Signal Range
|
±10V, ±5V, ±2.5V, 0-10V (configurable)
|
|
Output Signal
|
4-20mA, 0-10V (selectable per channel)
|
|
Power Supply
|
24V DC ±10%
|
|
Operating Temperature
|
-20°C to 70°C
|
|
IP Rating
|
IP20 (panel-mounted)
|
Key Features and Benefits
High-Precision Signal Processing: The IBA-SM128V incorporates advanced filtering and amplification technology to minimize noise and interference in analog signals. This ensures that even weak signals from sensors—such as temperature, pressure, or vibration transducers—are accurately captured and converted, providing reliable data for critical industrial decisions. The module’s low drift characteristics maintain measurement accuracy over time and temperature variations, which is crucial for long-term process stability.
Flexible Configuration: With 16 differential analog inputs and configurable input ranges (±10V, ±5V, ±2.5V, 0-10V), the
IBA-SM128V adapts to a wide variety of sensors and measurement requirements. Each channel can be independently set to output either 4-20mA or 0-10V, allowing seamless integration with PLCs, DCSs, and data acquisition systems. This flexibility eliminates the need for multiple specialized modules, reducing system complexity and cost.
Industrial-Grade Durability: Built to withstand harsh industrial conditions, the IBA-SM128V operates reliably within a temperature range of -20°C to 70°C. Its rugged design resists electrical noise, vibration, and humidity, making it suitable for use in factories, refineries, and power plants. The module’s short-circuit and overvoltage protection further enhance its longevity, minimizing downtime due to electrical faults.
Easy Integration and Scalability: The IBA-SM128V supports standard communication protocols for remote configuration and monitoring, enabling integration with IBA’s data acquisition software and third-party control systems. Its compact size allows for dense mounting in control cabinets, saving space in crowded industrial environments. Additionally, multiple IBA-SM128V modules can be daisy-chained to expand input capacity, providing a scalable solution for growing monitoring needs.
Related Models
- IBA-SM128A: A variant of the IBA-SM128V with current input ranges (4-20mA, 0-20mA), ideal for direct connection to loop-powered sensors.
- IBA-SM64V: A 64-channel version of the IBA-SM128V, designed for smaller-scale applications requiring fewer input channels.
- IBA-DM32: A digital input/output module that works with the IBA-SM128V to provide mixed-signal monitoring capabilities in industrial systems.
- IBA-SM128V-PRO: An upgraded model with enhanced diagnostic features, including channel-level fault detection and self-calibration, suitable for mission-critical applications.
- IBA-PC2: A data acquisition gateway that receives processed signals from the IBA-SM128V and transmits them to cloud-based monitoring platforms.
- IBA-SM256V: A high-density 32-channel module that extends the capabilities of the IBA-SM128V for large-scale industrial monitoring systems.
The
IBA-SM128V is backed by a one-year warranty, ensuring confidence in its performance and reliability. Our pre-sales team offers expert guidance to help configure the module for your specific sensor types and system requirements, while our after-sales support provides assistance with installation, calibration, and troubleshooting. This signal conditioning module is widely used in process industries for chemical and pharmaceutical production monitoring, in power generation for turbine and generator diagnostics, and in manufacturing for quality control of production lines. If you require a module with different input ranges or channel counts, or cannot find the model you need, please contact us immediately.
