IC693CPU372 is a TCP I/PI Ethernet communication interface. The module is primarily used to enable communication over Ethernet networks and supports system protocols such as Modbus TCP server/client and Industrial Ethernet. The module can be used to perform regular data exchange via Ethernet Global Data (EGD), SRTP, and SRTP clients.
The IC693CPU372 supports full PLC programming and configuration services. It comes with dual Ethernet ports that share the same IP address and serve as internal Ethernet switches, allowing Daisy chain connectivity for networking and implementing device level ring (DLR) topology. Each port supports automatic network sensing, eliminating the need to assign modules based on the speed of the existing network.
Brand :GE
Model :IC693CPU372-AE
Structure: modular
Installation method: Installation in control room
LD instruction processor: hard PLC
Function: Single slot CPU module with embedded Ethernet interface
Operating voltage: 12 volts DC
Processing speed: 133 MHZ
The IC693CPU372-AE CPU belongs to the GE Fanuc series 90-30 CPU. It is a single slot CPU module with an embedded Ethernet interface. It is based on the 386EX processor and offers fast computing and enhanced functionality. The IC693CPU372-AE CPU can handle up to 4096 I/0 discrete points, 2048 analog input points and 512 analog output points. The module is compatible with a range of fieldbus and device networks, such as Genius, Profibus-DP, DeviceNet, Interbus-S and CsCAN networks. Its internal power supply is required to be 1.4 amps at 5 volts DC. A Boolean instruction has a rated execution time of 0.15 microseconds.
The IC693CPU372-AE CPU is embedded in the backplane. It has a built-in 10/100 Mbps Ethernet port, an RS-485 port, a STRP channel, and network diagnostics tools. The CPU module supports several communication option modules, including Serial-SNP, SNPX, RTU and CCM, LAN-Genius, and Ethernet Modbus TCP client/server modules. It comes with a battery-powered clock. It does not support the handheld programmer module. This IC693CPU372 IC693CPU372-AE device. Each system has a total of eight backboards, including one CPU backboard and seven expansion backboards. It has communication and programmable coprocessor compatibility. The configuration and programming of the CPU module can be done through the Proficy Machine Edition Logic Developer package. The CPU supports hardware floating-point math and can be used for entry-level applications with low I/O counts.
The IC693CPU372 is part of the GE IC693CPU372 DC input interface circuit with an integrated interface for Ethernet communication. It has a filter circuit to eliminate the jitter of the input contacts, and a photoelectric coupling circuit to prevent the field of strong current interference into the PLC. Optical signal coupling is adopted between the input electrical signal and the PLC internal circuit to achieve complete electrical isolation, so that the input interface has anti-interference ability. The field input signal is converted into 5V TTL through photoelectric coupling and sent to the input data register, and then transmitted to the CPU through the data bus.
Features of the IC693CPU372 include full PLC programming and configuration services, with dual Ethernet ports that can be used as internal Ethernet switches, allowing daisy-chain connectivity for network and device-level ring network (DLR) topologies. Each port supports network automatic sensing, eliminating the need to assign modules to existing network speeds. It is equipped with a dedicated processor with a clock speed of 133 MHz and has the capability of 2048 discrete inputs, 2048 discrete outputs, 128-32,640 analog input words, and 128-32,640 analog output words (Max.) for a total user memory of 240 KB. In addition, it supports configuration with the Machine version of PLC Logic Developer for the Proficy Machine Edition package and has an integrated interface for Ethernet communication that can be used with hosts that have all the necessary software tools installed.
