The IC694MDL231 is a module provided by General Electric for use in PACSystems RX3i systems. It is a 240VAC isolated input module with the following features and functions:
Features:
Input number and type: The module provides 8 isolated input points, each with a common power input.
Input circuits: Input circuits are reactive (resistance/capacitance), which means they react quickly to input signals.
Supply voltage and range: The module is designed with a supply voltage of 240VAC and accepts voltage fluctuations between 200 and 264VAC. When the power supply is on, the voltage should be greater than 148VAC.
Current consumption: At 5VDC, the current consumption of the module is 60mA.
Communication interface: The module may have a communication interface that allows data communication and exchange with other devices or systems.
Features:
High flexibility: The rack-based IO design provides advanced diagnostic capabilities and flexibility to support a range of standard and advanced IO.
Advanced Diagnostics: Modules may have advanced diagnostic capabilities to help users quickly identify and resolve potential problems.
Wide range of applications: Suitable for mission-critical discrete and process applications to meet a variety of industrial automation and control needs.
Reliability and stability: The module is rigorously tested and verified to ensure stable operation in harsh industrial environments.
Ease of installation and maintenance: Modules are often designed with ease of installation and maintenance in mind, reducing the overall cost and time of the system.
