IC698CMX01 6 is a control memory switch module for the Programmable Automation Controller (PAC)PAC system RX7i platform. The component is essentially a storage module, but the main function of the IC698CMX016 is to use reflective storage technology to provide deterministic data sharing between PLCS and compatible devices on a fiber optic network.
The module is equipped with 16 MB SDRAM of parity checked reflected memory. It is mounted on the RX7i rack and occupies one slot in the backplane. This module is CPU independent because it does not require any CPU processing to run. In addition, it is compatible with the VMIC 5565 series reflective storage device network.
Brand: GE Fanuc
Series: PACSystem RX7i
Manufacturer: GE Intelligent Platform (former); Emerson Automation (current)
Manufacturer: GE Fanuc
Part number: IC698CMX016
Series: PACSystem RX7i
Product description: Control memory switch module
Description Control: Memory switch module
Part number: IC698CMX016
The IC698CMX016-ED is a control memory switch module designed to provide deterministic sharing of data between PLCS and compatible devices over a fiber optic network using reflective storage technology. It is equipped with 16MB SDRAM, operates at +5VDC, is supplied by the power supply, and the current requirement is 1.8 amps. This module needs to be mounted to the mainframe and connected to slot 3 or 4. It uses fiber LC type with insertion loss of 0.35 dB (maximum) and return loss of -30dB. The component is essentially a storage module, however, the main function of the IC698CMX016 is to provide deterministic data sharing between the PLC and compatible devices over a fiber optic network using reflective memory technology. The memory module is capable of communicating with up to 256 nodes per network and supports redundant transport mode operation.
The functions of the IC698CMX016-ED include:
Data storage and processing: As a control memory switch module, the IC698CMX016-ED is primarily used for data sharing between PLCS and compatible devices. It is equipped with 16MB of SDRAM, which can store and process large amounts of data.
Optical fiber communication: The module uses reflective storage technology to transmit data through optical fiber networks, with high transmission rate and reliability.
Redundant transmission mode: The IC698CMX016-ED supports redundant transmission mode operation, which can maintain continuous data transmission in the event of a network failure.
High reliability: The module has high reliability and stability, and can maintain normal operation in a variety of harsh environments.
Easy installation and maintenance: The module is easy to install and maintain, can be easily inserted into the corresponding slot, and has self-detection and alarm functions to facilitate timely detection and resolution of problems.
In summary, the IC698CMX016-ED is an efficient, reliable, and practical control memory switch module for a variety of applications requiring high data transfer rates and reliability.
The benefits of IC698CMX016-ED include:
High transmission rate: Data transmission through the fiber optic network, with a transmission rate of up to 2.12 Gbaud, can achieve high-speed data transmission.
Deterministic data sharing: Reflective storage technology enables deterministic data sharing between PLCS and compatible devices, ensuring data accuracy and consistency.
Redundant transmission mode: Supports the redundant transmission mode to maintain continuous data transmission when a network fault occurs, improving system reliability and stability.
Large capacity storage: Equipped with 16MB SDRAM, it can store large amounts of data to meet the needs of a variety of complex applications.
Reliability and stability: With high reliability and stability, it can maintain normal operation under various harsh environments and improve the availability and reliability of the system.
Easy to install and maintain: easy to install and maintain, can be easily inserted into the corresponding slot, and has self-detection and alarm functions, easy to find and solve problems in time.
In summary, the benefits of the IC698CMX016-ED include high transfer rates, deterministic data sharing, redundant transfer modes, mass storage, reliability and stability, and ease of installation and maintenance. These advantages make the module have wide application value in various application scenarios requiring high data transmission rate and reliability.
