Product Overview
The JSDU 2214-30slqta is a high-efficiency industrial power supply engineered for critical automation systems, delivering stable DC power to control modules, I/O units, and sensors in harsh industrial settings. Designed to meet the demands of process industries and discrete manufacturing, this power supply combines rugged construction with precise voltage regulation, ensuring uninterrupted operation even amid voltage fluctuations and environmental stress. Key features of the JSDU 2214-30slqta include wide input voltage compatibility, low output ripple, and built-in protection mechanisms—making it a reliable power source for DCS upgrades, servo drive systems, and packaging machinery control panels. The JSDU 2214-30slqta also supports seamless integration with legacy and modern automation setups, reducing retrofitting costs while enhancing system reliability.
Hainan Jinlin Mechanical & Electrical is a distributor of industrial control products, specializing in a wide range of brands. We possess extensive industry knowledge and market insights. Adhering to the "Customer First, Forge Ahead" business philosophy, we provide high-quality customer service. We're here for you, dedicated to meeting your needs!
Technical Specifications
|
Parameter
|
Value
|
|
Product Model
|
JSDU 2214-30slqta
|
|
Manufacturer
|
Industrial Power Supply Specialist
|
|
Product Type
|
Industrial DC Power Supply
|
|
Input Voltage Range
|
85-264V AC / 120-370V DC
|
|
Output Voltage & Current
|
24V DC @ 30A (720W maximum power)
|
|
Operating Temperature
|
-25°C to +70°C (-13°F to +158°F)
|
|
Output Ripple
|
≤ 50mV P-P
|
|
Protection Features
|
Overload, Overvoltage, Short-Circuit
|
|
Physical Dimensions
|
190mm (W) × 105mm (H) × 40mm (D)
|
Key Features and Benefits
Stable Power Delivery for Critical Loads
The JSDU 2214-30slqta delivers consistent 24V DC output at 30A, with ripple as low as 50mV P-P—critical for sensitive components like PLCs and sensors that require clean power to avoid data errors or malfunctions. Its wide input range (85-264V AC / 120-370V DC) accommodates unstable grid conditions common in manufacturing plants and remote power sites, eliminating the need for additional voltage regulators.
Robust Protection and Durability
Built for industrial resilience, the JSDU 2214-30slqta includes triple protection mechanisms: overload protection triggers at 110% of rated current, overvoltage protection activates at 28V DC, and short-circuit protection shuts down output instantly to prevent component damage. Its operating temperature range of -25°C to +70°C allows deployment in freezing warehouses, high-heat petrochemical facilities, and outdoor enclosures, reducing failure risks in extreme environments.
Space-Saving Design for Panel Integration
With dimensions of 190mm × 105mm × 40mm, the JSDU 2214-30slqta features a compact, low-profile form factor optimized for DIN-rail or panel mounting. This saves valuable space in control cabinets, where multiple power supplies and modules are often densely packed—ideal for retrofitting older systems or designing space-constrained automation setups.
Energy Efficiency and Cost Savings
The JSDU 2214-30slqta boasts high conversion efficiency (up to 94% at full load), minimizing energy waste and reducing operational costs over time. Lower heat generation from efficient operation also extends the lifespan of adjacent components in the control cabinet, further lowering maintenance and replacement expenses.
Related Models
- JSDU 2214-20slqta – Lower-current variant (20A) of the JSDU 2214-30slqta, ideal for smaller automation systems with lighter power demands.
- JSDU 2214-30slqta-P – Enhanced model with built-in power factor correction (PFC), complying with EN 61000-3-2 standards for grid-friendly operation in EU markets.
- JSDU 2215-30slqta – Upgraded version of the JSDU 2214-30slqta with RS485 communication, enabling remote monitoring of voltage, current, and temperature via Modbus RTU.
- JSDU 2214-30slqta-S – Safety-isolated variant (2500V AC isolation) of the JSDU 2214-30slqta, suitable for medical equipment or high-voltage industrial zones.
- JSDU 2213-30slqta – Previous generation of the JSDU 2214-30slqta, offering similar output but with a narrower input range (100-240V AC) and lower efficiency (88%).
- JSDU 2214-40slqta – Higher-power model (40A) compatible with the JSDU 2214-30slqta’s mounting footprint, for scaling up system power without redesigning cabinets.
Company and Service Highlights
As a certified partner of industry leaders such as Bentley Nevada, Honeywell, and ABB, we provide key components for process industries, discrete manufacturing, and infrastructure. Our expertise covers DCS upgrades, servo drive systems, and building automation—ensuring we understand your unique operational needs.
We prioritize professionalism in both pre-sales and after-sales service: our team offers technical consultations to confirm the JSDU 2214-30slqta’s compatibility with your existing systems, and we provide a one-year warranty on this product and all other offerings. If you cannot find the model you need, contact us immediately for personalized support.
