Product Overview
The 5X00481G04 is a high-performance digital output module designed for industrial control systems, serving as a critical interface between control units and field devices in automated processes. Developed with a focus on reliability and precision, this module is engineered to deliver consistent digital signals for activating actuators, relays, and other industrial equipment, making it indispensable in sectors such as pulp and paper, mining, and chemical processing. The 5X00481G04 is renowned for its seamless integration with METSO's control architectures, as well as compatibility with third-party systems, ensuring flexibility in diverse industrial setups. Whether controlling valve positions, motor starters, or alarm systems, this module provides the robust performance required to maintain smooth and efficient operations in demanding environments.
Technical Specifications
|
Parameter
|
Value
|
|
Product Model
|
5X00481G04
|
|
Manufacturer
|
METSO
|
|
Product Type
|
Digital Output Module
|
|
Output Channels
|
16 isolated channels
|
|
Output Signal Type
|
Relay contacts (NO/NC), 24 VDC solid-state outputs
|
|
Maximum Switching Current
|
5 A per channel (relay), 1 A per channel (solid-state)
|
|
Operating Voltage
|
24 VDC ±10%
|
|
Response Time
|
≤10 ms (relay), ≤1 ms (solid-state)
|
|
Isolation Rating
|
2.5 kV (channel to channel, channel to backplane)
|
|
Operating Temperature Range
|
-40°C to +70°C
|
|
Protection Features
|
Overcurrent protection, short-circuit protection
|
|
Mounting
|
DIN rail mounting (35mm)
|
|
Certifications
|
IEC 61131-2, CE, UL 508
|
Key Features and Benefits
The 5X00481G04 stands out for its versatile output capabilities, combining 16 isolated channels with both relay and solid-state output options. This dual functionality allows it to adapt to various field devices: relays handle higher current loads for equipment like motor starters, while solid-state outputs provide fast response times for precision applications such as valve control. The isolation rating of 2.5 kV ensures that electrical noise and voltage transients from field devices do not interfere with the control system, enhancing overall system stability.
A defining advantage of the 5X00481G04 is its robust protection mechanisms. Equipped with overcurrent and short-circuit protection, the module safeguards both itself and connected devices from damage caused by electrical faults. This feature is particularly critical in industrial environments where wiring errors or equipment malfunctions can occur, reducing downtime and maintenance costs. The module's ability to operate within a wide temperature range (-40°C to +70°C) further ensures reliability in extreme conditions, from freezing outdoor installations to hot industrial facilities.
Integration flexibility is another key strength of the 5X00481G04. It seamlessly connects with METSO's PLC and DCS systems via a backplane communication bus, enabling centralized control and monitoring. Additionally, its compliance with IEC 61131-2 standards ensures compatibility with third-party programming software, simplifying integration into mixed-vendor control architectures. This interoperability makes it an ideal choice for both new installations and system upgrades.
The 5X00481G04 also features advanced diagnostic capabilities. Each channel includes status indicators (LEDs) that provide real-time feedback on output activation and fault conditions, allowing operators to quickly identify issues such as open circuits or overloads. These diagnostics are accessible via the control system, enabling remote monitoring and proactive maintenance—critical for minimizing unplanned downtime in continuous-process industries.
Installation and maintenance of the 5X00481G04 are streamlined for efficiency. Its DIN rail mounting design allows for quick and secure installation, while pluggable terminal blocks simplify wiring and reduce setup time. The module's compact form factor optimizes space utilization in control cabinets, a valuable feature in crowded industrial environments. Furthermore, its hot-swappable design enables replacement without powering down the entire system, ensuring uninterrupted operation during maintenance.
Related Models
- 5X00482G04 – Enhanced version of the 5X00481G04 with 32 output channels, designed for large-scale applications requiring control of numerous field devices. It includes advanced surge protection for use in electrically noisy environments.
- 5X00480G04 – Predecessor to the 5X00481G04 with 8 channels and basic protection features, suitable for smaller systems or applications with lower I/O requirements.
- 5X00481G05 – Explosion-proof variant of the 5X00481G04, certified for ATEX Zone 2 and UL Class I Div 2, ideal for hazardous areas such as chemical storage facilities or oil refineries.
- 5X00481G06 – High-power model with relay outputs capable of switching up to 10 A per channel, designed for controlling heavy-duty equipment like large motors or heaters.
- 5X00481G07 – Fiber-optic isolated version of the 5X00481G04, providing enhanced electrical isolation (5 kV) for use in high-voltage industrial environments where noise immunity is critical.
- 5X00481G08 – Compact variant of the 5X00481G04 with a reduced footprint, optimized for space-constrained control cabinets in mobile or modular industrial systems.
-
- 5X00481G09 – Networked module with Ethernet/IP connectivity, enabling remote configuration and monitoring alongside the standard features of the 5X00481G04, suitable for distributed control systems.
-
We provide dedicated support for the 5X00481G04 and its related models. Our pre-sales team offers expert guidance on product selection and system integration, ensuring the 5X00481G04 aligns with your specific control requirements. Post-purchase, our after-sales service includes technical troubleshooting, calibration assistance, and firmware updates. All products come with a one-year warranty, protecting your investment in industrial control technology. If you need a model not listed or have customization needs, please contact us promptly.
