Product Overview
The NI PXIE-1078 is a high-performance 18-slot PXI Express (PXIe) chassis engineered for modular test, measurement, and automation systems across industries such as aerospace & defense, automotive, and electronics manufacturing. As a foundational component of National Instruments’ (NI) PXIe ecosystem, this chassis provides a rugged, high-bandwidth platform to integrate PXIe modules (e.g., data acquisition, signal generation, motion control) for synchronized, multi-channel testing. Key features of the NI PXIE-1078 include 18 hybrid slots (compatible with both PXIe and legacy PXI modules), integrated system timing/triggering, and high-power delivery—all optimized to minimize latency and ensure precise synchronization of up to 18 modular instruments. The NI PXIE-1078 integrates seamlessly with NI LabVIEW™ software and third-party automation tools (e.g., Python, MATLAB®), reducing system development time and enabling scalable test solutions. With a focus on reliability and flexibility, the NI PXIE-1078 is a trusted solution for industries where high-channel-count testing, low latency, and module compatibility directly impact test accuracy and operational efficiency.
Hainan Jinlin Mechanical & Electrical is a distributor of industrial control products, specializing in a wide range of brands. We possess extensive industry knowledge and market insights. Adhering to the "Customer First, Forge Ahead" business philosophy, we provide high-quality customer service. We're here for you, dedicated to meeting your needs!
Technical Specifications
|
Parameter
|
Value
|
|
Product Model
|
NI PXIE-1078
|
|
Manufacturer
|
National Instruments (NI)
|
|
Product Type
|
18-Slot PXI Express (PXIe) Chassis
|
|
Slot Configuration
|
18 Hybrid Slots (1 PXIe System Slot + 17 PXIe/PXI Compatibility Slots)
|
|
Maximum Bandwidth
|
8 GB/s (per PXIe x8 Slot)
|
|
System Timing
|
Integrated 10 MHz reference clock; PXIe Trigger Bus; Star Trigger Bus
|
|
Power Delivery
|
300 W Total Output (25 W per Slot, Max)
|
|
Operating Temperature
|
0°C to 55°C (Operating); -40°C to 70°C (Storage)
|
|
Cooling System
|
Front-to-Back Forced Air Cooling (Redundant Fans)
|
|
Form Factor
|
4U Rack-Mountable (19” Industrial Rack)
|
|
Compliance
|
CE, FCC Class A, UL/cUL 61010-1
|
Key Features and Benefits
The NI PXIE-1078 stands out for its technical versatility and practical value, making it a preferred choice for modular test and automation systems.
Scalable, Multi-Module Compatibility
With 18 hybrid slots (1 system slot + 17 compatibility slots), the NI PXIE-1078 supports both cutting-edge PXIe modules (e.g., NI PXIe-6363 DAQ) and legacy PXI modules—eliminating the need to replace existing hardware during system upgrades. This compatibility is critical for industries like automotive testing, where labs often use a mix of new and older instruments to test diverse components (e.g., engine sensors, infotainment systems). The 18-slot design also enables high-channel-count testing (e.g., 100+ analog input channels when paired with multi-channel DAQ modules), reducing the number of chassis needed and simplifying system cabling.
Precision Timing and Low Latency
The
NI PXIE-1078 features integrated timing and triggering capabilities that ensure sub-microsecond synchronization across all connected modules. Its 10 MHz reference clock and PXIe Trigger Bus enable precise alignment of test signals (e.g., synchronizing signal generators with data acquisition modules for radar testing in aerospace). The 8 GB/s per-slot bandwidth minimizes data transfer latency, critical for high-speed applications like semiconductor wafer testing—where delays in data capture can lead to inaccurate measurements of chip performance.
Rugged Design for Industrial Environments
Built to withstand industrial and lab-based rigors, the NI PXIE-1078 includes redundant front-to-back cooling fans that prevent overheating even when fully loaded with high-power modules (e.g., RF signal analyzers). Its 4U rack-mount form factor fits standard 19” industrial racks, optimizing space in test labs or factory floors. The chassis operates reliably in temperatures from 0°C to 55°C, making it suitable for both climate-controlled labs and semi-harsh factory environments (e.g., automotive production line testing). Additionally, compliance with UL/cUL 61010-1 and CE standards ensures safe operation in global markets.
Seamless Software Integration
The NI PXIE-1078 is natively supported by NI’s software ecosystem, including LabVIEW™, TestStand™, and NI-DAQmx drivers—enabling quick system configuration without custom coding. It also integrates with third-party tools like Python and MATLAB®, allowing engineers to use familiar programming environments. This software flexibility reduces development time: for example, a test engineer can program the chassis to automate a battery testing sequence in LabVIEW, then export data to MATLAB for analysis—all without switching hardware platforms.
Related Models
- NI PXIE-1071 – 1-slot Compact PXIe Chassis, ideal for portable test applications (e.g., field service diagnostics) where space is limited.
- NI PXIE-1075 – 5-slot PXIe Chassis, a smaller alternative to the NI PXIE-1078 for low-channel-count testing (e.g., benchtop electronics repair).
- NI PXIE-1079 – 18-slot High-Power PXIe Chassis, delivering 50 W per slot (vs. 25 W for NI PXIE-1078) for power-hungry modules (e.g., high-voltage signal generators).
- NI PXIE-1085 – 8-slot Rugged PXIe Chassis, rated for -40°C to +70°C operation (vs. 0°C to 55°C for NI PXIE-1078) for extreme environments (e.g., aerospace field testing).
- NI PXIE-1062Q – 6-slot PXIe Chassis with PCIe Gen 3 x16 Bandwidth, optimized for high-speed data streaming (e.g., 4K video testing in media equipment).
- NI PXIE-1073 – 3-slot PXIe Chassis, a cost-effective option for entry-level modular systems (e.g., university research labs).
Company & Service Highlights
Hainan Jinlin Mechanical and Electrical Equipment Co., Ltd., a distributor of industrial control products from various brands, specializes in selling industrial control products. Leveraging extensive industry knowledge and market insights, we adhere to the business philosophy of "Customer First, Striving for Progress" and prioritize customer service to provide customers with high-quality services. We are committed to serving your needs and are dedicated to meeting them!
As a certified partner of industry leaders such as Bentley Nevada, Honeywell, and National Instruments (NI), we provide key components for the following areas:
Typical Application Areas
- Aerospace & Defense: Multi-channel sensor testing (e.g., aircraft engine vibration monitoring) and radar signal analysis using the NI PXIE-1078 paired with PXIe RF modules.
- Automotive: End-of-line (EOL) testing of vehicle electronics (e.g., infotainment systems, ADAS sensors) with synchronized DAQ and signal generation modules.
- Electronics Manufacturing: Semiconductor wafer testing and consumer electronics (e.g., smartphone display) performance validation, leveraging high-channel-count DAQ modules.
- Research & Academia: Modular lab setups for physics experiments, biomedical signal analysis, and renewable energy (e.g., solar panel efficiency testing).
We offer a one-year warranty on the NI PXIE-1078 and all industrial control products, ensuring peace of mind for your investments. Our pre-sales team provides technical consultations to confirm module compatibility (e.g., power requirements, bandwidth needs) and system scaling, while our after-sales team offers on-site support for chassis installation, fan maintenance, and software configuration. If you cannot find the model you need, please contact us immediately.
