Item number: 3BSE092977R1
Class standard
Display type touch
Display size 7"
Brightness 350 cd/ m2
Display resolution, ratio 800 x 480 (16:9)
Processor ARM9 (1 GHZ)
Main memory 512 megabytes
External storage media is 2 GB (SSD) and 1.5 GB is available for application storage
Dimensions WxHxD (mm) 204 x 143 x 50 mm
Net weight (kg) 0.8
Power Supply + 24 V DC (18 to 32 V DC)
Operating temperature -10 °C to +60 °C
Characteristics and advantages
Easy to use
A fully deployable HMI, the PP875 features comprehensive and integrated templates and libraries for every process imaginable. The Panel Builder tool features the familiar Microsoft® Windows® environment and multi-language support for fast, simple, and efficient engineering.
State-of-the-art graphics
Vector-based, high-resolution graphics in the PP875 TFL/LED display with icon-based interface, navigation and control.
Solid and reliable
The Panel 800 is made with a robust and lightweight die-cast powder-coated aluminum housing. The front housing can withstand wet, dusty and harsh environments. The operating temperature ranges from -10°C to + 60°C with a maximum humidity of 85%.
A truly open platform
These panels are built on the open architecture and technology shipped with the.PP875 NET Framework, enabling multi-brand controller connectivity. Multiple connection options are available for local communication, extension, remote access, and more.
Before using the application first
Try it out before using the application, the PP875 can simulate and run applications directly from Panel Builder 800.
