Product Overview
The PR6423/01R-131+CON041 is a fully integrated eddy-current proximity probe and cable assembly from Bently Nevada, a global leader in machinery condition monitoring solutions. Designed exclusively for rotating equipment (e.g., turbines, compressors, motors), this combined system delivers precise measurements of radial vibration, shaft displacement, and rotational speed—critical data for preventing unplanned downtime and ensuring machinery safety. Key features of the PR6423/01R-131+CON041 include a 5mm linear measurement range, a pre-terminated CON041 cable (optimized for signal integrity), and compatibility with Bently Nevada’s 3500/40M and 1701 monitors. As a plug-and-play solution, the PR6423/01R-131+CON041 eliminates the need for separate probe-cable sourcing and termination, simplifying installation while maintaining industrial-grade reliability. It is an essential component for industries like power generation, oil & gas, and petrochemicals, where machinery health directly impacts operational efficiency and safety.
Hainan Jinlin Mechanical & Electrical is a distributor of industrial control products, specializing in a wide range of brands. We possess extensive industry knowledge and market insights. Adhering to the "Customer First, Forge Ahead" business philosophy, we provide high-quality customer service. We're here for you, dedicated to meeting your needs!
Technical Specifications
|
Parameter
|
Value
|
|
Product Model
|
PR6423/01R-131+CON041
|
|
Manufacturer
|
Bently Nevada
|
|
Product Type
|
Integrated Eddy-Current Probe + Pre-Terminated Cable Assembly
|
|
Measurement Range
|
5 mm (0.197 inches) linear range
|
|
Probe Diameter
|
11 mm (0.433 inches)
|
|
Cable Length (CON041)
|
3 meters (9.84 feet) shielded, pre-terminated
|
|
Output Signal
|
-2 V DC to -10 V DC (eddy-current voltage)
|
|
Operating Temperature
|
-54°C to +121°C (-65°F to +250°F)
|
|
Accuracy
|
±0.5% of full scale (at 25°C/77°F)
|
|
Compatibility
|
Bently Nevada 3500/40M, 1701, and 3300 Series Monitors
|
|
Cable Shielding
|
Double-shielded (foil + braid) for EMI/RFI protection
|
|
Connection Type
|
Miniature coaxial connector (matches Bently Nevada monitor inputs)
|
Key Features and Benefits
Integrated Design for Simplified Installation
The PR6423/01R-131+CON041 combines a high-performance proximity probe with a pre-terminated CON041 cable, eliminating the risk of poor termination (a common cause of signal loss in separate probe-cable setups). The cable is factory-tested to ensure optimal signal integrity, and its pre-attached connector snaps directly into Bently Nevada monitors—reducing installation time by up to 50% compared to traditional systems. This plug-and-play design also minimizes human error during setup, making it ideal for maintenance teams working in time-sensitive environments (e.g., power plant outages).
Precision Monitoring for Rotating Machinery
At the core of the
PR6423/01R-131+CON041 is Bently Nevada’s proven eddy-current technology, which delivers consistent, accurate measurements even in harsh industrial conditions. Its 5mm linear range captures subtle shaft movements (as small as 0.001 mm), enabling early detection of issues like bearing wear, shaft misalignment, or rotor imbalance—problems that can lead to catastrophic machinery failure if left unaddressed. The double-shielded
CON041 cable further enhances performance by blocking electromagnetic interference (EMI) from nearby motors or electrical equipment, ensuring stable signal transmission in noisy environments (e.g., petrochemical refineries).
Durability & System Compatibility
Built to withstand industrial rigor, the PR6423/01R-131+CON041 features a stainless steel probe housing that resists corrosion from oils, chemicals, and moisture—extending its lifespan in harsh operating conditions. The CON041 cable uses a rugged, oil-resistant jacket that tolerates exposure to industrial fluids, making it suitable for installation in tight or dirty machinery enclosures. Additionally, the assembly is fully compatible with Bently Nevada’s most widely used monitoring systems, including the 3500 Condition Monitoring System and 1701 Portable Monitor. This compatibility ensures seamless integration into existing setups, avoiding the need for costly system overhauls. Hainan Jinlin Mechanical & Electrical backs the PR6423/01R-131+CON041 with a one-year warranty, plus pre-sales technical support (e.g., verifying compatibility with your machinery) and after-sales assistance for calibration and troubleshooting.
Related Models
- PR6423/01R-131+CON042 – Variant of the PR6423/01R-131+CON041 with a 5-meter CON042 cable, ideal for machinery with longer installation distances .
- PR6423/02R-131+CON041 – Higher-sensitivity version of the PR6423/01R-131+CON041, optimized for low-amplitude vibration monitoring (e.g., precision centrifuges) .
- PR6424/01R-131+CON041 – Axial position probe assembly, complementary to the PR6423/01R-131+CON041, designed to measure shaft endplay in turbines .
- PR6423/01R-131+CON043 – High-temperature variant with a CON043 cable, rated for -54°C to +150°C (+302°F) for use in gas turbine enclosures .
- 3500/40M – Bently Nevada monitor that pairs with the PR6423/01R-131+CON041 to display, log, and alarm on vibration data .
- PR6423/01R-130+CON041 – Previous-generation model of the PR6423/01R-131+CON041, offering basic 4mm measurement range for legacy systems .
- PR6423/01R-131+CON044 – Explosion-proof cable variant (CON044) of the PR6423/01R-131+CON041, certified for Zone 1 hazardous areas (e.g., offshore oil rigs) .
Typical Application Areas
As a certified partner of industry leaders such as Bentley Nevada, Honeywell, and ABB, we provide key components for:
- Power Generation: Vibration and shaft position monitoring for steam turbines, gas turbines, and generators—where the PR6423/01R-131+CON041 helps prevent costly outages .
- Oil & Gas: Condition monitoring for pipeline compressors and wellhead pumps, leveraging the assembly’s EMI resistance to maintain accuracy in noisy refinery environments .
- Chemical Manufacturing: Shaft displacement tracking for agitator motors and process pumps, using the PR6423/01R-131+CON041’s precision to avoid product contamination from machinery failure .
We prioritize professionalism in pre-sales and after-sales service: our team can assist with probe alignment guidance, system compatibility checks, and calibration verification for the PR6423/01R-131+CON041. All products include a one-year warranty. If you cannot find the model you need, please contact us immediately.
