**Product Model: PSM0004 2RCA025059A0001
Brand:** ABB
Product Type: Push-button Module (for CP600 Control Panels)
Module Type:PS500 Series, 22.5mm wide
Function: Illuminated Push-button with a fixed LED color and legend
Legend/Color: Custom legend "PSM0004" with a specific LED color (e.g., white, red, green, amber - defined by suffix)
Contact Configuration: 1 Normally Open (NO) contact
Electrical Rating: 250VAC, 2A (AC-15); 125VDC, 0.1A (DC-13)
Voltage for LE, Typically 24 VDC (range 18-30 VDC), with integrated current-limiting resistor
Connection:Front-removable plug-in terminal blocks for easy wiring and replacemeFront Bezel Protection:** IP65 (when mounted in a panel)
---
Product Overview
The **PSM0004 2RCA025059A0001** is a specific, factory-configured illuminated push-button operator designed for ABB's CP600 series of modular control panels and system enclosures. The part number encodes a custom legend ("PSM0004") and a specific illuminated color. As part of the PS500 family, it features a modern, square-design keycap with integrated LED illumination for clear status indication. This module provides both a manual operator input (push-button) and a visual feedback signal, making it a fundamental component for human-machine interfaces (HMI) on machinery, control desks, and process panels where brand-specific or function-specific labeling is required.
**Key Features & Benefits**
* **Custom Branding & Clarity:** The fixed custom legend ("PSM0004") provides clear, permanent identification for a specific machine function, mode, or acknowledgment, reducing operator error and enhancing interface professionalism.
* **Integrated Visual Feedback:** The built-in LED illuminates upon command from the PLC (e.g., to indicate a machine is ready, a process is active, or an alarm is acknowledged), combining control and indication in a single, space-saving unit.
* **Modular & Service-Friendly Design:** As part of the CP600 system, it snaps into a standardized mounting rail alongside other operators (selectors, pilot lights). The front-removable terminals allow for quick wiring and replacement without disturbing adjacent modules or panel wiring.
* **Rugged Industrial Build:** The IP65 front protection rating makes it dust-tight and protected against low-pressure water jets, suitable for use in wash-down environments or industrial floors.
* **Consistent Aesthetics & Integration:** Ensures a uniform look and feel when used across an entire control panel, seamlessly integrating with other ABB CP600 HMI components for a cohesive operator station design.
---
**Core Adaptation Scenarios**
* **Scenario 1: Standardized Operator Interface on OEM Machinery**
An original equipment manufacturer (OEM) builds packaging machines shipped worldwide. They require a consistent, professional operator interface with machine-specific, non-generic labeling (e.g., "FILTER RESET", "JOG LEFT", "AUTO READY") that cannot be easily altered on-site.
* **Adaptation Solution:** Using custom-legend push-buttons like the **PSM0004 2RCA025059A0001** allows the OEM to design a clear, language-independent panel. The specific legend "PSM0004" corresponds to a defined function in the machine's manual. This standardizes the user experience across all units, reduces training needs, and presents a high-quality, integrated HMI. A food processing OEM uses this strategy to maintain branding and clarity across hundreds of installed machines.
* **Scenario 2: Modernization of Legacy Panels with Specific Labeling Needs**
A plant needs to replace a failed, obsolete illuminated push-button on a critical reactor control panel. The original button had a unique, etched legend that must be preserved for operational safety and procedures.
* **Adaptation Solution:** Sourcing a custom ABB **PSM0004 2RCA025059A0001** with an identical or functionally equivalent legend ("PSM0004") allows for a direct, drop-in functional and aesthetic replacement. It connects to the existing 24VDC supply and PLC input/output wiring, restoring the panel's original functionality and labeling without requiring a costly and confusing re-labeling of the entire panel. This is a common solution for life-extension projects in pharmaceuticals or chemicals where procedure compliance is paramount.
---
**Service Guarantee and Support**
* **Warranty Service:** This operator module is covered by a **12-month warranty**. We ensure it is free from defects in materials, workmanship, and that the legend/color matches the ordered specification.
* **Technical Support:** We provide expert assistance in decoding ABB's part number suffixes to confirm the exact legend and LED color. Support includes compatibility verification with your existing CP600 panel framework and dimensional drawings.
* **Reducing Decision-Making Concerns:** We specialize in OEM-style and replacement components. By providing the exact custom-configured part, we eliminate the risk of receiving a generic button that would compromise your panel's functionality or compliance with operational procedures.
---
**Related Product Recommendations**
* **CP600 Mounting Frame:** The **DRB500** series mounting base required to install this PS500 module onto a panel door.
* **Other PS500 Operators:** Illuminated push-buttons with different legends/colors, **selector switches**, **key-operated switches**, or **pilot light-only** modules to complete a control station.
* **CP600 Control Units:** The electronic **CU500** communication unit that interfaces a bank of these push-buttons with a PLC via PROFIBUS DP or PROFINET, drastically reducing individual wiring.
* **Blank Modules:** **PS500 Blanking modules** to fill unused spaces in the mounting frame for a finished appearance.
**If you require a different custom legend or cannot find this exact PSM0004 configuration, please contact us immediately for sourcing.**
