PXIe, 100 MHz, 32 channels, 3.3V PXI digital waveform instrument
The PXIe‑6544 is a digital waveform generator and analyzer for connecting 32 single-ended digital pins. The PXIe‑6544 is capable of sampling digital waveforms at rates up to 100 MHz and can be connected to commonly used transistor-transistor logic (TTL) voltage levels. The PXIe‑6544 also features advanced synchronization capabilities for building integrated mixed-signal test systems and digital timing capabilities for each storage unit.
Features:
Number of two-way digital channels: 32
Maximum clock rate
The onboard memory is 8Mbit
Signal type: single-ended
The PXIe-6544 is a digital waveform generator and analyzer designed to connect 32 single-ended digital pins. The PXIe-6544 can sample digital waveforms at frequencies up to 100 MHz and connect to common transistor-to-transistor logic (TTL) voltage levels. The PX-6544 also features advanced synchronization capabilities for building an integrated mixed-signal test system and digital timing capabilities for each set.
