Product Overview
The AKM22E-CKSNR-05 is a high-performance servo motor designed for precision motion control applications, delivering exceptional torque, speed, and positional accuracy across industrial automation systems. As a key component in advanced machinery, the AKM22E-CKSNR-05 excels in applications such as robotics, CNC machining, packaging equipment, and automated assembly lines—where precise movement and repeatability are critical to operational efficiency.
Core features of the AKM22E-CKSNR-05 include a high-resolution encoder, compact frame design, and robust construction, making it suitable for both space-constrained installations and demanding operating environments. Its seamless integration with servo drives ensures smooth, responsive performance, while its energy-efficient design reduces power consumption without compromising on output. With a focus on reliability, the AKM22E-CKSNR-05 is engineered to withstand continuous operation, minimizing downtime and maximizing productivity in high-cycle industrial processes.
Hainan Jinlin Mechanical & Electrical is a distributor of industrial control products, specializing in a wide range of brands. We possess extensive industry knowledge and market insights. Adhering to the "Customer First, Forge Ahead" business philosophy, we provide high-quality customer service. We're here for you, dedicated to meeting your needs!
Technical Specifications
|
Parameter
|
Value
|
|
Product Model
|
AKM22E-CKSNR-05
|
|
Manufacturer
|
Kollmorgen
|
|
Product Type
|
Servo Motor
|
|
Rated Power
|
0.5 kW (0.67 HP)
|
|
Rated Torque
|
1.59 Nm
|
|
Maximum Speed
|
3000 RPM
|
|
Encoder Type
|
20-bit absolute encoder
|
|
Voltage Rating
|
230 VAC (3-phase)
|
|
Operating Temperature
|
-15°C to 40°C (continuous operation)
|
|
Protection Class
|
IP65 (shaft and connectors)
|
|
Frame Size
|
22 mm (flange diameter)
|
Key Features and Benefits
Precision Motion Control
The
AKM22E-CKSNR-05 is equipped with a 20-bit absolute encoder, providing exceptional positional accuracy and repeatability (up to ±0.001°). This level of precision ensures consistent performance in applications like CNC milling, where tight tolerances are required for high-quality part production. The motor’s low cogging torque further enhances smoothness, reducing vibration and improving surface finishes in machining processes.
High Torque-to-Size Ratio
With a rated torque of 1.59 Nm in a compact 22 mm frame, the AKM22E-CKSNR-05 delivers an impressive power density, making it ideal for space-constrained machinery such as collaborative robots and small-scale packaging equipment. This compact design allows for flexible integration without sacrificing performance, enabling engineers to optimize machine layouts.
Durable and Reliable
Featuring an IP65 protection rating, the AKM22E-CKSNR-05 is resistant to dust and water jets, ensuring reliable operation in harsh industrial environments—including those with coolant, lubricants, or airborne particles. Its robust bearing system and high-grade materials support long service life, even under continuous operation, reducing maintenance requirements and total cost of ownership.
Seamless Drive Compatibility
The AKM22E-CKSNR-05 is designed to work seamlessly with Kollmorgen’s AKD series servo drives, as well as other industry-standard drives, simplifying system integration. This compatibility ensures optimal performance, with features like field-oriented control (FOC) enabling precise torque and speed regulation across the motor’s entire operating range.
Energy Efficiency
Engineered for low power consumption, the AKM22E-CKSNR-05 minimizes energy waste during both dynamic and static operation. Its high-efficiency design (up to 90%) reduces heat generation, allowing for cooler operation and extending the life of both the motor and surrounding components.
We stand behind the AKM22E-CKSNR-05 with a one-year warranty, supported by our team of motion control experts. From pre-sales system design to post-installation calibration, we provide tailored support to ensure the motor delivers optimal performance in your specific application.
Related Models
- AKM22E-CKSNR-03 – Lower-torque variant of the AKM22E-CKSNR-05 (1.0 Nm), suitable for lighter-load applications like small conveyors.
- AKM22E-CKSNR-07 – Higher-torque model (2.2 Nm) compatible with the AKM22E-CKSNR-05 for scaling systems with increased load demands.
- AKM22E-CKSMR-05 – Version of the AKM22E-CKSNR-05 with a 17-bit incremental encoder, ideal for cost-sensitive applications where absolute positioning is not required.
- AKD-P00606-NBAN-0000 – Kollmorgen servo drive specifically matched to the AKM22E-CKSNR-05 for optimized performance.
- AKM23E-CKSNR-05 – Larger-frame (23 mm) motor with similar features to the AKM22E-CKSNR-05, offering higher torque (3.0 Nm) for heavier loads.
- MPS200 – Motor protection module for the AKM22E-CKSNR-05, providing overcurrent and overtemperature safeguards in critical systems.
- AKM22E-CKSNR-05-H – High-temperature variant of the AKM22E-CKSNR-05, rated for operation up to 60°C, suitable for hot industrial environments.
As a certified distributor of Kollmorgen and other leading motion control brands, we specialize in delivering reliable servo solutions. Our pre-sales team can assist with motor selection and system integration, while after-sales support includes troubleshooting, maintenance training, and repair services. The
AKM22E-CKSNR-05 comes with a one-year warranty. For more details or to inquire about related products, contact us via WhatsApp: [
