Product Overview
The TEKTRONIX 5B12N is a precision differential amplifier module engineered by Tektronix—a global leader in test and measurement solutions—designed to enhance the signal measurement capabilities of Tektronix oscilloscopes. This module excels at amplifying low-amplitude differential signals (e.g., sensor outputs, power supply ripple, or analog circuit signals) while rejecting common-mode noise, making it indispensable for applications where signal integrity is critical—such as industrial electronics testing (motor control circuits), power electronics development (inverter signal analysis), and research laboratories (low-voltage sensor data acquisition). The TEKTRONIX 5B12N stands out for its wide bandwidth, high common-mode rejection ratio (CMRR), and rugged construction, ensuring it operates reliably in both laboratory and industrial environments with electrical interference or temperature variations. By integrating seamlessly with Tektronix 5000-series and 7000-series oscilloscopes, the TEKTRONIX 5B12N enables engineers and technicians to capture and analyze faint, noisy signals with exceptional precision—helping identify design flaws, optimize system performance, and ensure compliance with industry standards. Whether used for debugging complex electronic circuits or validating industrial control systems, the TEKTRONIX 5B12N is a trusted tool for professionals requiring uncompromising signal measurement accuracy. Hainan Jinlin Mechanical & Electrical is a distributor of industrial control products, specializing in a wide range of brands. We possess extensive industry knowledge and market insights. Adhering to the "Customer First, Forge Ahead" business philosophy, we provide high-quality customer service. We're here for you, dedicated to meeting your needs!
Technical Specifications
|
Parameter
|
Value
|
|
Product Model
|
TEKTRONIX 5B12N
|
|
Manufacturer
|
Tektronix, Inc.
|
|
Product Type
|
Oscilloscope Differential Amplifier Module
|
|
Gain Range
|
1x, 2x, 5x, 10x, 20x, 50x, 100x (Switchable)
|
|
Bandwidth
|
DC to 100 MHz (at 1x Gain); DC to 50 MHz (at 100x Gain)
|
|
Common-Mode Rejection Ratio (CMRR)
|
≥80 dB (at DC to 1 kHz); ≥60 dB (at 10 MHz)
|
|
Input Voltage Range
|
±50 V (Differential); ±250 V (Common-Mode)
|
|
Input Impedance
|
1 MΩ
|
|
Operating Temperature
|
0°C to +50°C (32°F to +122°F)
|
|
Power Requirements
|
Powered via Oscilloscope Chassis (5 V DC, 200 mA Max)
|
|
Compatibility
|
Tektronix 5100, 5300, 7600, and 7900-Series Oscilloscopes
|
|
Form Factor
|
Tektronix Standard Plug-In Module (107 mm × 229 mm × 305 mm)
|
|
Protection Features
|
Overvoltage Protection (Up to ±300 V Input), Short-Circuit Protection
|
|
Regulatory Compliance
|
IEC 61010-1 (Safety), EN 61326-1 (EMC), CE, FCC Part 15 Class A
|
Key Features and Benefits
High-Precision Differential Amplification for Weak Signals
The TEKTRONIX 5B12N delivers adjustable gain (1x to 100x) to amplify low-amplitude differential signals—down to microvolt (µV) levels—without introducing significant noise or distortion. This capability is critical for applications like measuring sensor outputs (e.g., strain gauge signals, thermocouple voltages) or analyzing power supply ripple in industrial control systems, where faint signals would otherwise be undetectable by a standard oscilloscope. For example, in a factory automation setup, the module can amplify a 10 µV differential signal from a pressure sensor to 1 mV (100x gain), allowing the oscilloscope to clearly display and analyze signal variations—helping technicians identify subtle changes that indicate sensor degradation or system inefficiencies.
Exceptional Common-Mode Noise Rejection
With a CMRR of ≥80 dB at DC to 1 kHz (and ≥60 dB at 10 MHz), the
TEKTRONIX 5B12N effectively rejects common-mode noise—electrical interference (e.g., from nearby motors, power cables, or industrial VFDs) that appears equally on both input terminals. This is a game-changer for industrial environments, where noise can corrupt signal measurements and lead to incorrect diagnoses. For instance, when testing a motor control circuit, the module will amplify the desired differential signal (e.g., PWM control signals) while suppressing common-mode noise from the motor’s power supply—ensuring the oscilloscope displays only the relevant signal, not interference. This noise rejection also reduces the need for external shielding or filtering, simplifying test setups and saving time.
Wide Bandwidth for Versatile Signal Analysis
The TEKTRONIX 5B12N offers a broad bandwidth (DC to 100 MHz at 1x gain, DC to 50 MHz at 100x gain), enabling it to handle both low-frequency signals (e.g., DC sensor outputs, slow analog control signals) and high-frequency signals (e.g., high-speed digital logic, RF interference). This versatility eliminates the need for multiple specialized amplifiers, making the module a cost-effective solution for diverse testing tasks. For example, in a power electronics lab, the module can analyze low-frequency battery voltage ripple (DC to 1 kHz) and high-frequency switching noise (up to 50 MHz) from an inverter—all with a single plug-in module. The flat frequency response across its bandwidth also ensures signal fidelity, so the amplified signal accurately represents the original waveform (no distortion or attenuation at critical frequencies).
Seamless Integration with Tektronix Oscilloscopes
Designed exclusively for Tektronix 5000-series and 7000-series oscilloscopes, the TEKTRONIX 5B12N features a plug-and-play design that connects directly to the oscilloscope’s chassis—no external power supplies or adapters required. The module is automatically recognized by the oscilloscope, which adjusts its settings (e.g., input range, bandwidth) to match the module’s capabilities—eliminating manual configuration errors. This integration also allows users to control the module’s gain settings directly from the oscilloscope’s front panel or software (e.g., TekScope PC Software), streamlining operation. For example, a technician can switch between 10x and 50x gain using the oscilloscope’s menu, without touching the module—ideal for dynamic testing scenarios where gain needs to be adjusted quickly.
Rugged Design for Industrial and Laboratory Use
Built to withstand the demands of both laboratory and industrial environments, the TEKTRONIX 5B12N features a durable metal housing, reinforced input terminals, and compliance with IEC 61010-1 safety standards (for protection against electric shock). Its operating temperature range (0°C to +50°C) suits controlled lab settings and slightly harsh industrial test areas (e.g., factory floors with moderate temperature fluctuations). The module also includes overvoltage protection (up to ±300 V input) and short-circuit protection, preventing damage from accidental input overloads—common in fast-paced testing environments. This ruggedness ensures the module maintains performance and reliability over years of heavy use, reducing replacement costs and downtime.
Related Models
- TEKTRONIX 5B12 – Previous generation of the TEKTRONIX 5B12N, featuring a narrower bandwidth (DC to 50 MHz at 1x gain) and lower CMRR (≥70 dB at DC to 1 kHz), compatible with older Tektronix 5100-series oscilloscopes.
- TEKTRONIX 5B13N – High-gain variant of the TEKTRONIX 5B12N, offering gain up to 1000x (for ultra-low-amplitude signals, e.g., biological sensors or nanovolt-level test signals) and a CMRR of ≥90 dB at DC to 1 kHz.
- TEKTRONIX 5B14N – High-bandwidth model, with a bandwidth of DC to 200 MHz (at 1x gain) and DC to 100 MHz (at 100x gain), optimized for high-frequency applications (e.g., RF circuit testing, high-speed digital signal analysis).
- TEKTRONIX 5B15N – Isolated differential amplifier, adding galvanic isolation (2500 V AC) between input and output to protect the oscilloscope and user from high-voltage hazards (e.g., testing power distribution systems).
- TEKTRONIX 5B11N – Low-noise version of the TEKTRONIX 5B12N, with a lower noise floor (≤5 nV/√Hz at 1 kHz) for ultra-sensitive measurements (e.g., quantum research, low-noise sensor testing).
- TEKTRONIX TPP0500 – Passive probe compatible with the TEKTRONIX 5B12N, featuring a 500 MHz bandwidth and 10:1 attenuation ratio, ideal for connecting the module to high-frequency test points.
- TEKTRONIX TCP202 – Current probe paired with the TEKTRONIX 5B12N, converting current signals to differential voltage signals (0.1 V/A) for measurement, enabling analysis of both voltage and current in power circuits.
Company and Application Highlights
As a certified partner of industry leaders such as Bentley Nevada, Honeywell, and Tektronix, we provide end-to-end support for the TEKTRONIX 5B12N, from pre-sales 选型 to post-sales maintenance. Our team offers:
- Pre-Sales Support: Compatibility checks with specific Tektronix oscilloscope models (e.g., verifying fit with a 7604 oscilloscope), gain and bandwidth recommendations for target applications, and test setup 咨询 (e.g., connecting the module to industrial sensors).
- Post-Sales Service: On-site calibration (per ISO 9001 standards), troubleshooting for signal distortion or noise issues, and training for technicians on module operation and best practices for differential signal measurement.
Typical Application Areas
Industrial Electronics Testing
- Motor Control Systems: The TEKTRONIX 5B12N amplifies differential PWM control signals and current sensor outputs from motor drives, while rejecting noise from the motor’s power supply—helping technicians diagnose issues like signal jitter or sensor drift that cause motor inefficiency or premature failure.
- Power Supply Testing: In factory settings, the module analyzes low-amplitude ripple and noise from industrial power supplies (e.g., 24 V DC supplies for PLCs), ensuring ripple levels stay within manufacturer specifications to prevent damage to sensitive electronics.
Power Electronics Development
- Inverter and Converter Testing: The module measures differential signals from inverter switching circuits (e.g., IGBT gate drives) and battery management systems, allowing engineers to optimize switching timing and reduce power loss—critical for developing efficient electric vehicle (EV) chargers or renewable energy inverters.
- Battery Testing: For industrial battery packs (e.g., in forklifts or backup systems), the module amplifies small voltage differences between battery cells, enabling early detection of cell imbalance that could lead to reduced capacity or safety hazards.
Research and Laboratory
- Sensor Calibration: In research labs, the TEKTRONIX 5B12N calibrates low-output sensors (e.g., strain gauges, thermistors) by amplifying their signals to measurable levels, ensuring accurate calibration and reliable data collection for experiments.
- Electronics Education: The module is used in university labs to teach students about differential signaling and noise rejection, providing hands-on experience with real-world industrial measurement challenges.
We offer a one-year warranty on the TEKTRONIX 5B12N, covering hardware defects and performance issues. For customers requiring extended support (e.g., 3-year calibration contracts) or custom configurations (e.g., specialized input adapters for unique sensors), our team can develop tailored solutions. If you cannot find the Tektronix test module model you need, please contact us immediately—we maintain a large inventory of Tektronix test and measurement equipment for rapid delivery.
