Product Overview
The TEWS TVME200-10 is a high-reliability 6U VMEbus carrier module engineered by TEWS Technologies— a leader in industrial embedded computing—designed to enable flexible, modular I/O expansion for mission-critical industrial control systems. This robust platform serves as a bridge between VMEbus-based host systems and Industry Pack (IP) modules (single or double-size), making it ideal for applications requiring customizable I/O configurations such as process control, medical equipment, telecommunications infrastructure, and traffic management systems. Unlike potential misclassifications as a power supply, the TEWS TVME200-10’s core function is to provide standardized connectivity, power distribution, and interrupt management for IP modules—delivering exceptional flexibility, temperature resilience, and long-term stability in harsh industrial environments.
Certified to ANSI/VITA 4-1995 standards (the industry benchmark for VMEbus-IP integration), the TEWS TVME200-10 supports up to 4 single-size or 2 double-size IP modules, allowing engineers to mix-and-match I/O functions (e.g., analog input, digital output, communication interfaces) without redesigning the entire system. Its rugged construction—featuring corrosion-resistant alloys, self-healing power fuses, and RF filtering—ensures reliable operation in extreme conditions, from -40°C cold storage facilities to +85°C factory floors. By integrating seamlessly with third-party VMEbus systems (e.g., GE Fanuc VME controllers, Emerson PACSystems) and IP modules (e.g., TEWS IP-CANopen, Analog Devices IP-A/D), the TEWS TVME200-10 reduces system development time, lowers maintenance costs, and extends the lifecycle of legacy industrial equipment.
Hainan Jinlin Mechanical & Electrical is an authorized distributor of industrial embedded components, including TEWS Technologies products. With deep expertise in VMEbus and IP module ecosystems, we provide end-to-end support—from system compatibility testing to on-site installation—to ensure the TEWS TVME200-10 delivers optimal performance for your specific application. Adhering to our "Customer First, Forge Ahead" philosophy, we prioritize tailored solutions that meet the unique demands of industrial automation, process control, and critical infrastructure projects.
Technical Specifications
|
Parameter
|
Value
|
|
Product Model
|
TEWS TVME200-10
|
|
Manufacturer
|
TEWS Technologies
|
|
Product Type
|
6U VMEbus Industry Pack (IP) Carrier Module
|
|
Form Factor
|
6U VMEbus Board (160mm x 233.35mm)
|
|
VMEbus Compliance
|
ANSI/VITA 4-1995 (VMEbus Slave Interface)
|
|
IP Module Support
|
Up to 4 Single-Size IP Modules or 2 Double-Size IP Modules
|
|
VMEbus Addressing
|
Short I/O: 16-bit Address, 8/16-bit Data (1 kByte); Standard Memory: 24-bit Address, 8/16-bit Data (32 kB–2 MB per IP); Extended Memory: 32-bit Address, 8/16-bit Data (8 MB fixed per IP)
|
|
Interrupt Management
|
IRQ 1–7 (software-programmable or rotary switch-selectable routing from IP modules to VMEbus)
|
|
Interface Speed
|
8 MHz (no DMA support)
|
|
I/O Connectivity
|
50-pin 0.1-inch Flat Ribbon Cable (FRC) Connector per IP Slot (front-panel access)
|
|
Power Distribution
|
+5 V, +12 V, -12 V (self-healing fuses and RF filtering on all IP power lines)
|
|
Status Indicators
|
ACK LED per IP Module; +5 V LED per IP Slot; +12 V/-12 V System LEDs
|
|
Operating Temperature
|
-40°C to +85°C (Industrial Temperature Range)
|
|
Storage Temperature
|
-55°C to +125°C
|
|
Regulatory Compliance
|
CE, RoHS 2 (Restriction of Hazardous Substances)
|
|
Mechanical Durability
|
Vibration Resistance: 10 G (10–2000 Hz); Shock Resistance: 50 G (11 ms Half-Sine)
|
Key Features and Benefits
Modular I/O Flexibility for Customized Systems
The
TEWS TVME200-10 eliminates the need for fixed-function I/O boards by supporting up to 4 single-size IP modules—enabling engineers to tailor I/O configurations to specific application needs. For example, in a water treatment plant’s process control system, the carrier can host 2 analog input IP modules (for pressure/temperature sensing), 1 digital output IP module (for valve control), and 1 communication IP module (for Ethernet connectivity)—all within a single 6U VMEbus slot. This modularity reduces inventory costs (no need to stock specialized boards) and simplifies upgrades: replacing an outdated IP module (e.g., legacy serial communication) with a modern variant (e.g., CANopen) requires no changes to the carrier or host system.
Robust Power Protection and Signal Integrity
TEWS’s integrated power management safeguards both the carrier and connected IP modules from damage. Self-healing fuses on all IP power lines automatically reset after overloads (e.g., short circuits in IP modules), eliminating the need for manual fuse replacement and reducing downtime. RF filtering minimizes electromagnetic interference (EMI) from nearby industrial equipment—critical for sensitive applications like medical imaging systems, where signal noise could corrupt patient data. In a telecommunications base station, for instance, the RF filtering ensures IP-based signal processing modules maintain consistent performance despite high EMI from transmitters.
Extreme Temperature Resilience for Harsh Environments
With an operating temperature range of -40°C to +85°C, the TEWS TVME200-10 outperforms commercial-grade VMEbus carriers and is qualified for use in extreme industrial settings. In a mining control system, where ambient temperatures can drop to -30°C and rise to +70°C, the carrier maintains stable power distribution and interrupt routing for IP modules monitoring conveyor belt tension and underground gas levels. Its corrosion-resistant alloy housing also withstands humidity (up to 95% non-condensing) and chemical exposure—making it suitable for offshore oil rigs or chemical processing plants.
Simplified Configuration and Maintenance
The TEWS TVME200-10 streamlines system setup with dual configuration options: software-programmable interrupt routing (for dynamic adjustments) and a 16-position rotary switch (for predefined interrupt sets). This flexibility caters to both automated production lines (where software reconfiguration is preferred) and remote infrastructure (where manual adjustments may be necessary). Status LEDs provide real-time visibility into system health: an unlit +5 V LED for an IP slot immediately indicates a power issue, allowing technicians to quickly isolate faulty modules. For example, in a traffic control system, a technician can identify a failed IP-based traffic light controller by checking the carrier’s ACK LED—reducing troubleshooting time from hours to minutes.
Seamless Integration with Legacy and Modern Systems
As a ANSI/VITA 4-1995 compliant module, the TEWS TVME200-10 works with both legacy VMEbus hosts (e.g., 1990s-era GE Fanuc controllers) and modern embedded systems (e.g., Emerson PACSystems RX3i). Its 50-pin FRC connectors are compatible with standard IP module cabling, eliminating the need for custom harnesses. In a factory retrofit, for instance, the carrier can be installed in an existing VMEbus chassis to add Ethernet connectivity (via an IP-Ethernet module) to a legacy motor control system—extending the system’s lifecycle by 10+ years without replacing the host controller.
Related Models
- TEWS TVME200 – Base model of the TVME200-10, offering identical VMEbus and IP support but without the -10 submodel’s enhanced RF filtering (ideal for less EMI-sensitive environments like laboratory automation).
- TEWS TVME200-10R – Ruggedized variant with reinforced shock resistance (100 G vs. 50 G) and extended temperature range (-55°C to +95°C), designed for aerospace or military applications (e.g., aircraft engine monitoring).
- TEWS TVME300 – 9U VMEbus carrier supporting up to 8 single-size IP modules, suitable for high-density I/O applications like data centers or large-scale process control systems.
- TEWS IP-CANopen – Compatible IP module for the TVME200-10, providing CANopen communication for industrial networks (e.g., connecting to PLCs or motor drives).
- TEWS IP-AI16 – 16-channel analog input IP module, ideal for pairing with the TVME200-10 in temperature/pressure sensing applications (e.g., food processing lines).
- TEWS TVME200-ED – Engineering documentation kit for the TVME200-10, including schematics, data sheets, and configuration guides to support system design and integration.
Company and Application Highlights
As a certified distributor of TEWS Technologies and a partner of industry leaders (e.g., GE Fanuc, Emerson, Analog Devices), we provide comprehensive support for the TEWS TVME200-10 throughout its lifecycle:
Pre-Sales Support
- System Compatibility Testing: Verify integration with your existing VMEbus host (e.g., GE Fanuc 90-30) and IP modules (e.g., third-party analog output boards).
- Configuration Consulting: Recommend IP module combinations for your application (e.g., 2 IP-AI16 + 1 IP-DO32 for a chemical plant’s process control system).
- Thermal Analysis: Ensure the TVME200-10 operates within temperature limits for your environment (e.g., adding heatsinks for +85°C factory floors).
Post-Sales Service
- On-Site Installation: Guide your team through chassis mounting, IP module insertion, and cabling (e.g., connecting FRC cables to front-panel sensors).
- Performance Validation: Test interrupt routing, power distribution, and signal integrity to confirm compliance with your system requirements.
- Training Programs: Offer hands-on training for technicians on module replacement, fuse reset procedures, and LED status interpretation.
Typical Application Areas
Process Control
- Chemical Manufacturing: Hosts IP modules for pH sensing (analog input), pump control (digital output), and safety interlocks (relay output)—enabling real-time monitoring of reaction vessels.
- Water Treatment: Integrates IP-based flow meters and valve controllers to regulate water purification processes, with the TVME200-10’s RF filtering ensuring accurate sensor data.
Medical Equipment
- Imaging Systems: Supports IP modules for data acquisition and signal processing in MRI or CT scanners, where the carrier’s low EMI ensures image clarity.
- Patient Monitoring: Hosts IP modules for vital sign sensing (e.g., heart rate, blood pressure) and alarm triggers, with self-healing fuses preventing power failures during critical procedures.
Telecommunications
- Base Stations: Integrates IP-Ethernet and IP-Serial modules to manage data flow between cell towers and core networks, with the carrier’s temperature resilience ensuring operation in remote, unconditioned locations.
- Network Switches: Hosts IP modules for traffic shaping and error detection, reducing latency in 5G infrastructure.
Traffic Management
- Signal Control: Supports IP modules for traffic light timing and pedestrian crossing triggers, with the TVME200-10’s shock resistance surviving road vibrations.
- Camera Surveillance: Integrates IP-video processing modules to monitor traffic flow, with interrupt routing ensuring real-time alerts for accidents or congestion.
We offer a two-year warranty on the TEWS TVME200-10, covering hardware defects and performance issues. For customers requiring extended support (e.g., 5-year maintenance contracts) or custom modifications (e.g., enhanced EMI shielding for military applications), our engineering team can develop tailored solutions. If you need assistance selecting compatible IP modules or verifying VMEbus host compatibility, please contact us—we maintain a large inventory of TEWS products for rapid delivery.
