Product Overview
The TRACO POWER T1032-07C is a compact, high-efficiency industrial DC-DC converter engineered to deliver stable, isolated DC power for sensitive electronics in harsh industrial environments—including automation control systems, process sensors, PLC modules, and telecommunications equipment. As a critical component in power distribution chains, this converter transforms unregulated input voltage (e.g., from industrial batteries or power supplies) into precise, isolated output voltage, protecting connected devices from voltage fluctuations, noise, and ground loops. Core features of the TRACO POWER T1032-07C include wide input voltage range, high isolation voltage, ruggedized design, and low electromagnetic interference (EMI), ensuring reliable operation in settings with temperature extremes, vibration, or electrical noise. By providing efficient power conversion (up to 90% efficiency) and robust protection against electrical hazards, the TRACO POWER T1032-07C helps minimize equipment downtime, extend the lifespan of sensitive electronics, and maintain uninterrupted operation of industrial processes—making it an indispensable solution for industrial power management.
Hainan Jinlin Mechanical & Electrical is a distributor of industrial control products, specializing in a wide range of brands. We possess extensive industry knowledge and market insights. Adhering to the "Customer First, Forge Ahead" business philosophy, we provide high-quality customer service. We're here for you, dedicated to meeting your needs!
Technical Specifications
|
Parameter
|
Value
|
|
Product Model
|
TRACO POWER T1032-07C
|
|
Manufacturer
|
TRACO POWER (global leader in industrial power conversion solutions)
|
|
Product Type
|
Isolated Industrial DC-DC Converter
|
|
Input Voltage Range
|
9–36 V DC (wide input for industrial applications)
|
|
Output Voltage
|
7.5 V DC (regulated, ±1% tolerance)
|
|
Output Current
|
1.3 A (continuous), 2.6 A (peak for 10 seconds)
|
|
Power Output
|
10 W (continuous)
|
|
Isolation Voltage
|
1.5 kV DC (input to output, for 1 minute)
|
|
Efficiency
|
Up to 90% (at full load, 24 V DC input)
|
|
Ripple & Noise
|
<50 mV p-p (at full load)
|
|
Protection Features
|
Overload (120–150% rated current), short-circuit, overvoltage, overtemperature protection
|
|
Operating Temperature
|
-40°C to +85°C (-40°F to +185°F)
|
|
Vibration Resistance
|
Operating: 10 G (10–2000 Hz, per IEC 60068-2-6); Non-operating: 30 G (10–2000 Hz)
|
|
Shock Resistance
|
Operating: 50 G (1ms, half-sine, per IEC 60068-2-27); Non-operating: 100 G (1ms)
|
|
Form Factor
|
Encapsulated (epoxy resin), through-hole mounting (DIP-24 package)
|
|
Dimensions (L×W×H)
|
38.1mm × 24.1mm × 10.2mm (1.5” × 0.95” × 0.4”)
|
|
Certifications
|
IEC/EN 62368-1 (safety), EN 55032 Class B (EMI), UL 62368-1, CE, RoHS compliant
|
Key Features and Benefits
The
TRACO POWER T1032-07C delivers exceptional reliability, efficiency, and protection—addressing critical challenges in industrial power conversion.
Wide Input Range for Versatile Integration
With a 9–36 V DC wide input range, the TRACO POWER T1032-07C accommodates variable industrial power sources, such as 12 V/24 V batteries, unregulated power supplies, or fluctuating grid-fed DC systems. This versatility eliminates the need for multiple converters to match different input voltages, simplifying system design and reducing inventory costs. For example, in mobile industrial equipment (e.g., forklifts or portable test tools), it maintains stable output even as battery voltage drops during discharge—ensuring consistent performance of connected sensors or control modules.
High Isolation & EMI Compliance for Device Protection
The 1.5 kV DC input-to-output isolation protects sensitive electronics from ground loops, voltage transients, and electrical noise—common in industrial environments with multiple high-power devices (e.g., motors, inverters). This isolation prevents damage to PLCs or sensors caused by ground potential differences, while compliance with EN 55032 Class B (EMI) ensures the converter does not emit interference that could disrupt nearby communication or control systems. For applications like process automation, this translates to more accurate sensor readings and fewer false triggers in control logic.
Rugged Encapsulated Design for Harsh Conditions
Encapsulated in epoxy resin and built to withstand extreme temperatures (-40°C to +85°C), the TRACO POWER T1032-07C operates reliably in unconditioned spaces—such as outdoor equipment enclosures, factory floors, or oil and gas field instruments. It resists vibration (10 G during operation) and shock (50 G during operation), making it suitable for mounted applications on machinery or mobile platforms. The encapsulated design also provides dust and moisture resistance (equivalent to IP65 when properly mounted), further extending its lifespan in harsh settings.
High Efficiency & Low Power Loss
Boasting up to 90% efficiency at full load, the TRACO POWER T1032-07C minimizes power loss, reducing heat generation and eliminating the need for bulky heat sinks. This efficiency is critical for battery-powered applications (e.g., remote monitoring sensors), where lower power consumption extends battery life and reduces maintenance frequency. For 24/7 industrial systems, it also lowers long-term energy costs—especially in large-scale deployments with dozens of converters.
Compact Size & Easy Installation
With a small form factor (38.1mm × 24.1mm × 10.2mm) and through-hole DIP-24 package, the TRACO POWER T1032-07C fits into space-constrained PCBs or control modules. Its standard pin configuration simplifies PCB layout, while the encapsulated design eliminates the need for additional housing—reducing overall system size and cost. Clear labeling of input/output pins also speeds up installation and reduces wiring errors, making it ideal for high-volume manufacturing or field retrofits. Paired with our one-year warranty and technical support (including thermal management guidance), this ensures seamless deployment and long-term reliability.
Related Models
- TRACO POWER T1032-05C – Lower-output-voltage variant of the TRACO POWER T1032-07C (5 V DC, 2 A); ideal for powering low-voltage electronics (e.g., microcontrollers, LED status lights).
- TRACO POWER T1032-12C – Higher-output-voltage model (12 V DC, 0.83 A); designed for equipment requiring 12 V power (e.g., small fans, wireless communication modules).
- TRACO POWER T1032-07C-H – High-isolation upgrade (3 kV DC input-to-output); suitable for safety-critical applications (e.g., medical equipment, high-voltage test systems) requiring enhanced electrical safety.
- TRACO POWER T2032-07C – Higher-power variant (20 W, 7.5 V DC, 2.6 A); intended for larger loads (e.g., multiple sensors, small PLC modules) that exceed the 10 W capacity of the TRACO POWER T1032-07C.
- TRACO POWER T1048-07C – Wide-input-range model (18–75 V DC); optimized for 48 V industrial systems (e.g., telecom base stations, heavy machinery) while maintaining 7.5 V output.
- TRACO POWER T1032-07C-S – Surface-mount (SMD) version; designed for compact PCB designs (e.g., portable industrial sensors) where through-hole mounting is not feasible.
