| Product Model | TSXDSY16R5 |
| Manufacturer | Schneider Electric |
| Product Type | Digital Output Module |
| Outputs | 16 relay outputs |
The TSXDSY16R5 is a high-performance digital output module designed for Schneider Electric’s TSX premium PLC series. Renowned for its reliability and precision, the TSXDSY16R5 delivers stable and accurate switching performance in demanding industrial automation applications. Engineered for seamless integration, it ensures optimal communication with PLC systems, allowing precise control of actuators, relays, and other output devices.
The TSXDSY16R5 is widely applied in process control, discrete manufacturing, and energy automation systems. Its modular design enables straightforward installation into existing TSX PLC racks, ensuring both system scalability and flexibility. Compact yet robust, the module is built to operate reliably under harsh environmental conditions, including temperature variations and electrical noise.
Hainan Jinlin Mechanical & Electrical is a distributor of industrial control products, specializing in a wide range of brands. We possess extensive industry knowledge and market insights. Adhering to the "Customer First, Forge Ahead" business philosophy, we provide high-quality customer service. We're here for you, dedicated to meeting your needs!
| Parameter | Value |
|---|---|
| Product Model | TSXDSY16R5 |
| Manufacturer | Schneider Electric |
| Product Type | Digital Output Module |
| Outputs | 16 relay outputs |
| Output Type | 24 VDC / 230 VAC selectable |
| Dimensions | Compact, rack-mountable |
| Operating Temp. | 0°C to +60°C |
| Mounting | PLC rack / DIN rail |
The TSXDSY16R5 delivers precise and reliable digital output performance for industrial automation applications. Its 16-channel configuration allows efficient control of multiple devices simultaneously, making it ideal for complex process control and discrete manufacturing systems.
With robust relay outputs, the TSXDSY16R5 supports both DC and AC load types, providing flexibility in controlling a wide range of actuators, solenoids, and indicator devices. The module also features rapid response times, ensuring real-time system performance and minimizing operational delays.
Reliability is a key advantage. The TSXDSY16R5 is built to withstand electrical noise, voltage fluctuations, and environmental stress, maintaining stable operation even in challenging industrial conditions. Its diagnostic capabilities enable quick fault detection and troubleshooting, reducing maintenance time and enhancing overall system efficiency.
Integration is seamless with Schneider Electric TSX PLC systems, offering compatibility with existing modules and easy scalability for system expansions. The durable design, coupled with compact dimensions, makes the TSXDSY16R5 suitable for tight installation spaces while ensuring long-term operational stability.
TSXDSY16R6 – Upgraded model with faster switching response.
TSXDSY08R5 – 8-channel variant suitable for smaller PLC configurations.
TSXDSY32R5 – Expanded 32-channel output module for high-capacity systems.
TSXDSY16R4 – Previous generation model with standard relay outputs.
TSXDSY16D5 – Digital transistor output version for low-voltage DC control.
TSXDSY16R7 – Advanced relay output module with enhanced diagnostics.
