GE VME-PMC-CADDY Product Description
Product Overview
The GE VME-PMC-CADDY is a specialized interface and mounting solution designed for integrating PMC (PCI Mezzanine Card) modules into VMEbus-based industrial computing systems. As a critical component in GE's portfolio of industrial computing accessories, this caddy provides a secure and efficient way to connect PMC modules to VMEbus backplanes, ensuring seamless communication and optimal performance. The VME-PMC-CADDY is engineered to meet the rugged demands of industrial environments, with a robust construction that withstands vibration, shock, and temperature variations. Whether used in military applications, aerospace systems, or industrial automation control panels, the GE VME-PMC-CADDY facilitates reliable integration of high-performance PMC modules, enhancing the functionality and expandability of VME-based systems.
Technical Specifications
|
Parameter
|
Value
|
|
Product Model
|
VME-PMC-CADDY
|
|
Manufacturer
|
GE
|
|
Product Type
|
PMC to VME Interface Caddy
|
|
Compatibility
|
VMEbus systems, PMC modules (IEEE 1386.1)
|
|
Dimensions
|
160mm × 100mm × 50mm
|
|
Operating Temperature
|
-40°C to +85°C
|
|
Mounting Type
|
Rack-mount within VME chassis
|
|
Material
|
Anodized aluminum alloy
|
|
Weight
|
350g
|
Key Features and Benefits
Secure Module Integration
The
GE VME-PMC-CADDY features a precision-engineered housing that securely holds PMC modules in place, preventing movement even in high-vibration environments. Its robust clamping mechanism ensures a stable connection between the PMC module and the VMEbus backplane, eliminating signal interruptions caused by loose connections. This secure integration is critical for mission-critical applications where system downtime is not acceptable.
Seamless Signal Transmission
Designed with high-quality electrical connectors, the VME-PMC-CADDY ensures low-loss signal transmission between PMC modules and the VMEbus. It maintains impedance matching across all signal paths, minimizing electromagnetic interference (EMI) and ensuring data integrity at high transfer rates. This feature is especially important for applications involving real-time data processing, such as radar systems or industrial control loops.
Rugged Environmental Resistance
Constructed from anodized aluminum alloy, the
GE VME-PMC-CADDY offers excellent resistance to corrosion, impact, and extreme temperatures. Its ability to operate in the -40°C to +85°C range makes it suitable for deployment in harsh environments, including outdoor industrial sites, military vehicles, and aerospace ground support equipment. The material's durability also extends the service life of both the caddy and the installed PMC module.
Easy Installation and Maintenance
The VME-PMC-CADDY is designed for tool-less installation, allowing technicians to quickly insert or remove PMC modules without disassembling the VME chassis. Its clear labeling of connectors and alignment guides simplifies the installation process, reducing setup time and minimizing the risk of incorrect connections. For maintenance, the caddy can be easily accessed within the VME chassis, enabling fast module replacement or upgrades.
Versatile Compatibility
Supporting all standard PMC modules compliant with IEEE 1386.1, the GE VME-PMC-CADDY offers broad compatibility with a wide range of functional modules, including communication cards, data acquisition boards, and processing accelerators. This versatility allows system integrators to customize VMEbus systems according to specific application requirements, enhancing system flexibility and reducing the need for custom interface solutions.
Related Models
- GE VME-PMC-CADDY-EXT – An extended version with additional cooling fins, designed for high-power PMC modules that generate significant heat.
- GE VME-PMC-CADDY-LT – A lightweight variant (280g) with a reinforced plastic frame, ideal for weight-sensitive applications such as unmanned aerial vehicles (UAVs).
- GE VME-PCIe-CADDY – A compatible interface caddy for integrating PCIe mezzanine cards into VMEbus systems, offering a transition path for newer module standards.
- GE PMC-IO-ADAPTER – A companion adapter that extends the I/O capabilities of PMC modules when used with the VME-PMC-CADDY.
- GE VME-CHASSIS-10U – A 10U VME chassis optimized for use with the VME-PMC-CADDY and multiple PMC modules in industrial control systems.
- GE VME-PMC-CADDY-RED – A redundant configuration model with dual connectors, ensuring failover capability in safety-critical applications like nuclear power plant controls.
We provide a one-year warranty for the
GE VME-PMC-CADDY, backed by our professional pre-sales and after-sales support. Our technical team can assist with system integration guidance, ensuring optimal compatibility between the caddy, PMC modules, and VMEbus infrastructure. If you require a specific configuration or cannot find the model you need, please contact us immediately. The
GE VME-PMC-CADDY and its related models are trusted in industries such as defense, aerospace, energy, and industrial automation, enabling reliable and flexible system expansion.
