Product Overview
The YASKAWA CP-317/217IF is a high-performance communication interface module engineered to enable seamless data exchange between Yaskawa’s servo drives, inverters, and upper-level control systems (such as PLCs, HMI, or SCADA). As a critical connectivity hub in industrial automation, this module eliminates communication bottlenecks, ensuring real-time transmission of control signals, status data, and diagnostic information—essential for synchronizing processes in dynamic manufacturing environments. Key features of the YASKAWA CP-317/217IF include multi-protocol support, high data transfer rates, and robust anti-interference capabilities, making it ideal for applications requiring precise coordination, such as automotive assembly lines, CNC machine tools, and material handling systems. Fully integrated into Yaskawa’s automation ecosystem, the YASKAWA CP-317/217IF simplifies system setup and reduces compatibility risks, while its industrial-grade design ensures reliable operation in harsh conditions (e.g., high vibration, temperature variations). For engineers seeking to optimize communication efficiency in Yaskawa-based systems, the YASKAWA CP-317/217IF stands as a trusted, future-proof solution.
Hainan Jinlin Mechanical & Electrical is a distributor of industrial control products, specializing in a wide range of brands. We possess extensive industry knowledge and market insights. Adhering to the "Customer First, Forge Ahead" business philosophy, we provide high-quality customer service. We're here for you, dedicated to meeting your needs!
Technical Specifications
|
Parameter
|
Value
|
|
Product Model
|
YASKAWA CP-317/217IF
|
|
Manufacturer
|
Yaskawa
|
|
Product Type
|
Communication Interface Module
|
|
Supported Protocols
|
EtherCAT, Modbus RTU/TCP, PROFINET IO
|
|
Data Transfer Rate
|
Up to 1 Gbps (EtherCAT/PROFINET)
|
|
Operating Temperature
|
-10°C to +55°C (14°F to +131°F)
|
|
Power Supply
|
24 V DC ±10% (1.5 W max consumption)
|
|
Connection Ports
|
2 x RJ45 (EtherCAT/PROFINET), 1 x RS485 (Modbus RTU)
|
|
Mounting Type
|
DIN Rail (35 mm standard) / Panel Mount
|
|
IP Rating
|
IP20 (front panel)
|
Key Features and Benefits
The YASKAWA CP-317/217IF redefines communication efficiency in industrial automation, addressing critical pain points like protocol incompatibility, data latency, and system complexity:
Multi-Protocol Versatility
With native support for EtherCAT, Modbus RTU/TCP, and PROFINET IO, the
YASKAWA CP-317/217IF acts as a universal bridge between Yaskawa drives and diverse control systems. This eliminates the need for multiple interface modules—for example, it can connect a Yaskawa Sigma-7 servo drive to a Siemens PLC (via PROFINET) and a local HMI (via Modbus TCP) simultaneously. This versatility reduces hardware costs and simplifies system architecture, especially in mixed-vendor automation setups.
Real-Time Data Transmission
Boasting a data transfer rate of up to 1 Gbps (for EtherCAT and PROFINET), the YASKAWA CP-317/217IF ensures near-zero latency in signal transmission. This is critical for high-speed applications like CNC machining or robotic pick-and-place systems, where even millisecond delays can cause process errors or product defects. The module’s deterministic communication also enables precise synchronization of multiple Yaskawa drives, improving overall production accuracy.
Robust Anti-Interference Design
Built with industrial-grade EMI (Electromagnetic Interference) shielding and surge protection, the YASKAWA CP-317/217IF maintains stable communication even in noisy environments—common near high-power motors, welding equipment, or industrial heaters. This prevents data corruption or signal drops, reducing unplanned downtime and ensuring consistent system performance in sectors like automotive manufacturing or metal processing.
Simplified Setup & Diagnostics
The YASKAWA CP-317/217IF supports Yaskawa’s MotionWorks IEC software, which provides intuitive tools for protocol configuration, parameter adjustment, and real-time diagnostics. Engineers can quickly troubleshoot communication issues (e.g., port errors, protocol mismatches) via the software’s visual dashboard, eliminating the need for specialized testing equipment. Additionally, the module stores historical error logs, enabling proactive maintenance and root-cause analysis.
Wide Environmental Adaptability
Operating within a temperature range of -10°C to +55°C and compatible with 24 V DC power supplies (±10% tolerance), the YASKAWA CP-317/217IF performs reliably in extreme industrial conditions—from cold storage facilities to high-temperature assembly plants. Its dual mounting options (DIN Rail/panel) also offer flexibility for space-constrained control cabinets, adapting to diverse installation requirements.
Related Models
- YASKAWA CP-316/216IF – Previous generation of the YASKAWA CP-317/217IF, with basic protocol support (Modbus RTU/EtherCAT only) for legacy systems.
- YASKAWA CP-318/218IF – Upgraded model of the YASKAWA CP-317/217IF, adding Ethernet/IP protocol support for Allen-Bradley PLC compatibility.
- YASKAWA CP-320/220IF – High-density variant of the YASKAWA CP-317/217IF, with 4 RJ45 ports for connecting multiple drives simultaneously.
- YASKAWA SI-P3 – Servo interface module (companion to the YASKAWA CP-317/217IF), optimizing signal transmission between Yaskawa Sigma-5 drives and the interface.
- YASKAWA E700-IF – Inverter-specific interface module, compatible with the YASKAWA CP-317/217IF for expanding communication options in Yaskawa V1000/V700 inverters.
- YASKAWA CP-317/217IF-D – Dust-resistant version of the YASKAWA CP-317/217IF (IP54 rating) for harsh environments like cement plants or mining operations.
Company Expertise & Warranty
As a certified partner of industry leaders such as Yaskawa, Honeywell, and ABB, we provide genuine, high-quality industrial control components like the YASKAWA CP-317/217IF. Our team offers specialized pre-sales support—including protocol compatibility checks for Yaskawa drive-PLC integrations—and comprehensive after-sales service, such as on-site configuration assistance. All products, including the YASKAWA CP-317/217IF, come with a 1-year warranty to cover manufacturing defects and ensure long-term reliability.
Typical Application Areas
- Discrete Manufacturing: Enabling communication between Yaskawa servo drives and PLCs in automotive assembly lines (e.g., robotic welding arms) and CNC machine tools (e.g., precision milling machines).
- Material Handling: Synchronizing Yaskawa inverters (for conveyor belts) with SCADA systems via the YASKAWA CP-317/217IF, ensuring smooth product flow in warehouses or distribution centers.
- Packaging Machinery: Connecting Yaskawa motion controllers to HMIs using Modbus TCP, allowing operators to monitor and adjust packaging speeds in real time.
If you cannot find the model you need (e.g., other Yaskawa communication modules or components from TRICONEX/Bently Nevada), please contact us immediately for personalized support.
