Product Overview
The YASKAWA JACP-317802 is a precision-engineered industrial interface module designed to facilitate seamless signal conversion, transmission, and synchronization between Yaskawa’s motion control systems and a wide range of external devices—including sensors, actuators, HMIs, and third-party PLCs. As a critical connectivity component in Yaskawa’s automation ecosystem (often paired with MP series motion controllers and Sigma servo drives), this module addresses the challenge of integrating diverse hardware in complex industrial setups, where incompatible signal types or protocols can create data bottlenecks. What sets the YASKAWA JACP-317802 apart is its multi-signal support (analog/digital, serial/Ethernet) and robust signal conditioning, ensuring accurate data transfer even in high-noise industrial environments—making it essential for time-sensitive applications like robotic assembly, CNC machining, and precision material handling.
Key features of the YASKAWA JACP-317802 include compact DIN-rail compatible design, 24 VDC low-power operation, and compliance with global industrial standards (CE, UL, CSA). It seamlessly integrates with Yaskawa’s MP 920/MP2300iec motion controllers and Sigma-5/Sigma-7 servo drives (e.g., CACR-HR10BB), enabling unified control over multi-axis systems. Whether converting analog sensor signals to digital for the controller or transmitting motion status data to an HMI, the YASKAWA JACP-317802 ensures signal integrity via built-in noise filtering and error correction, minimizing operational downtime and maximizing production accuracy.
Hainan Jinlin Mechanical & Electrical is a trusted distributor of industrial control products, offering a comprehensive range of brands including Yaskawa. With extensive expertise in automation system integration, we adhere to the "Customer First, Forge Ahead" business philosophy, delivering tailored solutions to meet your connectivity needs—from pre-sales compatibility checks to post-sales technical support.
Technical Specifications
|
Parameter
|
Value
|
|
Product Model
|
YASKAWA JACP-317802
|
|
Manufacturer
|
YASKAWA
|
|
Product Type
|
Industrial Interface Module (Signal Conversion & Transmission)
|
|
Supported Signal Types
|
Analog (4-20mA DC, 0-10V DC); Digital (24V DC, NPN/PNP); Serial (RS-485); Ethernet (10/100 Base-T)
|
|
Signal Conversion
|
Analog-to-Digital (16-bit resolution); Digital-to-Analog (16-bit resolution); Serial-to-Ethernet (Modbus RTU/TCP)
|
|
Number of Channels
|
8 analog I/O channels; 16 digital I/O channels; 1 RS-485 port; 1 Ethernet port
|
|
Data Transfer Rate
|
Up to 100 Mbps (Ethernet); 115.2 kbps (RS-485)
|
|
Compatibility
|
Yaskawa MP 920/MP2300iec Motion Controllers, Sigma-5/Sigma-7 Servo Drives, CP-317 Base Module; Third-party PLCs (Siemens S7, Allen-Bradley ControlLogix)
|
|
Power Requirement
|
24 VDC ±10%; 300 mA maximum current draw
|
|
Safety Certifications
|
CE, UL, CSA; IEC 61000-6-2 (EMI immunity)
|
|
Signal Conditioning
|
Built-in low-pass filter (50/60Hz notch filter); ESD protection (±15kV contact)
|
|
Housing Material
|
Flame-retardant plastic (UL94 V-0 rating); gold-plated terminal contacts
|
|
Protection Rating
|
IP20 (module); NEMA 1 (panel-mounted with CP-317 base)
|
|
Operating Temperature
|
-10°C to +60°C (ambient, non-condensing)
|
|
Storage Temperature
|
-20°C to +85°C
|
|
Dimensions (L×W×H)
|
120mm × 80mm × 65mm (module only)
|
|
Weight
|
Approximately 0.4 kg (module only)
|
|
Mounting Type
|
DIN-rail compatible (via CP-317 base module)
|
|
Connection Interface
|
Screw terminals (analog/digital); RJ45 (Ethernet); 5-pin terminal block (RS-485)
|
|
MTBF (Mean Time Between Failures)
|
> 800 years (per industrial reliability standards)
|
Key Features and Benefits
Multi-Signal Support for Versatile Integration
The YASKAWA JACP-317802 excels at bridging diverse signal types, supporting analog (4-20mA, 0-10V), digital (24V DC), serial (RS-485), and Ethernet signals—eliminating the need for multiple single-function modules. For example, in a CNC machining center, the module can convert analog spindle speed signals (4-20mA from a tachometer) to digital for the MP2300iec controller, while simultaneously transmitting digital limit switch status (24V DC) to a third-party HMI via Ethernet. This versatility simplifies system architecture, reduces hardware costs, and is ideal for retrofits where legacy analog sensors coexist with modern digital controllers.
High-Precision Signal Conversion for Accurate Control
Equipped with 16-bit analog-to-digital (A/D) and digital-to-analog (D/A) converters, the YASKAWA JACP-317802 ensures minimal signal distortion—critical for precision applications like semiconductor wafer handling or robotic welding. The 16-bit resolution translates to a measurement accuracy of ±0.0015% FS for analog signals, meaning a 4-20mA pressure sensor reading is converted with a margin of error as small as 0.024mA. In a robotic assembly line, this precision ensures the controller receives exact force feedback from a load cell (via 4-20mA), allowing the robot arm to apply consistent pressure during component insertion—reducing part damage and improving assembly yield.
Robust Noise Immunity for Harsh Environments
Engineered to resist electromagnetic interference (EMI) and electrical noise, the YASKAWA JACP-317802 includes built-in 50/60Hz notch filters (to suppress power line noise) and ESD protection (±15kV contact) to shield against static discharges. This makes it reliable in noisy industrial settings, such as metal fabrication plants with nearby welding equipment or automotive factories with high-voltage motors. Unlike generic interface modules, it maintains signal integrity even in environments with EMI levels up to 10V/m (per IEC 61000-6-2), preventing data corruption that could lead to incorrect machine operation or safety hazards.
Seamless Integration with Yaskawa Automation Ecosystem
As a native Yaskawa component, the YASKAWA JACP-317802 integrates plug-and-play with MP series motion controllers and Sigma servo drives, using Yaskawa’s proprietary communication protocols to avoid compatibility issues. Via SigmaWin+ configuration software, technicians can easily map channels (e.g., assign analog input 1 to spindle speed), adjust filter settings, and monitor signal status in real time—no custom programming required. For instance, when paired with a CACR-HR10BB servo drive, the module automatically detects the drive’s signal requirements and configures A/D conversion parameters, reducing setup time by up to 35% compared to third-party modules. It also supports Modbus RTU/TCP for seamless communication with Yaskawa’s 218IF communication module, enabling end-to-end data flow from sensors to MES systems.
Compact Design and Low Power Consumption
The
YASKAWA JACP-317802 features a space-saving form factor (120×80×65mm) and DIN-rail mounting (via the CP-317 base module), making it ideal for crowded control cabinets—common in multi-axis systems like 6-axis robots or CNC mills with multiple I/O points. Its low power consumption (24 VDC, 300 mA) reduces load on industrial power supplies and generates minimal heat, eliminating the need for additional cooling fans. In a compact semiconductor manufacturing tool, for example, multiple JACP-317802 modules can be mounted on a single DIN rail alongside drives and controllers, optimizing cabinet space without sacrificing functionality.
Related Models
- YASKAWA JACP-317802/CP Bundle – Complete interface package including the JACP-317802 module, CP-317 base module, and terminal blocks, pre-wired for immediate deployment.
- YASKAWA JACP-317803 – High-channel variant of the JACP-317802 (16 analog I/O, 32 digital I/O), designed for large-scale systems (e.g., factory-wide sensor networks).
- YASKAWA JACP-317802-E – EtherCAT-enabled variant, optimized for ultra-high-speed synchronization (sub-millisecond latency) in multi-axis robotic systems (e.g., 12-axis pick-and-place machines).
- YASKAWA JACP-317802-P – Profinet-enabled variant, tailored for integration into Siemens PLC-based systems (e.g., automotive paint shops using Siemens S7-1500 controllers).
- YASKAWA JACP-317802-S – Safety-certified variant (SIL 2) of the JACP-317802, with redundant signal paths for safety-critical applications (e.g., emergency stop systems, pressure relief valve control).
- YASKAWA JACP-317801 – Basic variant of the JACP-317802 (4 analog I/O, 8 digital I/O), cost-effective for small-scale applications (e.g., standalone conveyors, lab automation equipment).
Company & Service Highlights
Hainan Jinlin Mechanical and Electrical Equipment Co., Ltd. is a leading distributor of industrial control products, partnering with industry giants such as Yaskawa, Yokogawa, and Honeywell. With years of experience in automation system integration, we offer:
- Genuine Yaskawa Interface Solutions: All YASKAWA JACP-317802 modules are 100% original, with full manufacturer documentation (including certification records) to ensure compliance with industrial standards. We also provide pre-configured bundles (e.g., JACP-317802 + CP-317 + SigmaWin+ software) for plug-and-play deployment.
- Expert Compatibility Support: Our team of Yaskawa-certified engineers offers free pre-sales consultation to verify compatibility with your existing system (e.g., checking if the JACP-317802 works with your MP 920 controller or third-party PLC). We also provide on-site integration services to calibrate signal conversion and ensure seamless data flow.
- Fast Delivery & Stock Availability: We maintain regional stock of the YASKAWA JACP-317802 and its related modules, enabling delivery within 2-4 business days for urgent system repairs or upgrades. For large-volume orders, we offer customized delivery schedules to align with your production timeline.
- Warranty & Maintenance: We offer a one-year warranty on the YASKAWA JACP-317802, with optional extended maintenance contracts that include annual calibration, firmware updates, and priority technical support.
Typical Application Areas
- Robotics: Converting force/torque sensor signals (4-20mA) to digital for Yaskawa MP2300iec controllers in 6-axis welding robots, ensuring precise weld pressure and reducing defect rates.
- CNC Machining: Transmitting analog spindle temperature data (0-10V) from a thermocouple to the controller, enabling real-time thermal compensation for machining accuracy.
- Automotive Assembly: Integrating digital proximity sensors (24V DC) with third-party PLCs via Modbus TCP, synchronizing part feeding with robotic assembly to optimize cycle times.
- Semiconductor Manufacturing: Converting analog vacuum pressure signals (4-20mA) from wafer processing chambers to digital, ensuring consistent pressure levels for chip fabrication and complying with cleanroom standards.
If you need to verify compatibility of the YASKAWA JACP-317802 with your existing automation system or require assistance with signal mapping, please contact us today for tailored support.
