Product Overview
The YASKAWA LASC-100SUB is a specialized industrial sub-module engineered to enhance the functionality of Yaskawa’s LASC (Linear Servo Control) systems, focusing on high-precision linear motion control for demanding automation applications. As a critical expansion component in Yaskawa’s motion control ecosystem, this sub-module addresses the need for enhanced position feedback, synchronization, and error correction in linear servo systems—common in industries such as semiconductor manufacturing, flat-panel display production, and precision machining. What sets the YASKAWA LASC-100SUB apart is its support for high-resolution linear encoders, real-time position compensation, and seamless integration with Yaskawa’s Sigma series servo drives (e.g., CACR-HR10BB) and MP series motion controllers.
Key features of the YASKAWA LASC-100SUB include compact DIN-rail compatible design, 24 VDC low-power operation, and compliance with global industrial standards (CE, UL, CSA). It excels in applications requiring sub-micron positioning accuracy—such as linear stages for wafer inspection or laser cutting systems—by minimizing linear motion errors (e.g., pitch, yaw, roll) through advanced signal processing. Whether used to expand encoder input capabilities or enable multi-axis linear synchronization, the YASKAWA LASC-100SUB ensures reliable, consistent performance in harsh industrial environments, making it an indispensable component for precision linear motion systems.
Hainan Jinlin Mechanical & Electrical is a trusted distributor of industrial control products, offering a comprehensive range of brands including Yaskawa. With extensive expertise in automation system integration, we adhere to the "Customer First, Forge Ahead" business philosophy, delivering tailored solutions to meet your linear motion control needs—from pre-sales compatibility checks to post-sales technical support.
Technical Specifications
|
Parameter
|
Value
|
|
Product Model
|
YASKAWA LASC-100SUB
|
|
Manufacturer
|
YASKAWA
|
|
Product Type
|
Industrial Linear Servo Control Sub-Module (LASC System Expansion)
|
|
Supported Encoders
|
Linear encoders (absolute: up to 25-bit; incremental: up to 1,000,000 ppr);
|
|
Positioning Accuracy
|
±0.1 μm (with high-resolution linear encoder input)
|
|
Synchronization Support
|
Multi-axis linear motion synchronization (up to 4 axes via LASC system)
|
|
Error Correction
|
Pitch/yaw/roll error compensation; Thermal expansion compensation
|
|
Communication Interface
|
LASC bus (for connection to Yaskawa LASC main controller); RS-485 (Modbus RTU for configuration)
|
|
Input/Output (I/O)
|
4 digital input channels (24V DC, NPN/PNP); 2 digital output channels (24V DC, 0.5A max)
|
|
Power Requirement
|
24 VDC ±10%; 200 mA maximum current draw
|
|
Safety Certifications
|
CE, UL, CSA; IEC 61000-6-2 (EMI immunity)
|
|
Signal Conditioning
|
Built-in differential signal receiver (for encoder noise reduction); ESD protection (±15kV contact)
|
|
Housing Material
|
Flame-retardant plastic (UL94 V-0 rating); Aluminum heat-dissipating base
|
|
Protection Rating
|
IP20 (sub-module); NEMA 1 (panel-mounted with LASC main controller)
|
|
Operating Temperature
|
0°C to +55°C (ambient, non-condensing; derating above 45°C)
|
|
Storage Temperature
|
-20°C to +85°C
|
|
Dimensions (L×W×H)
|
100mm × 70mm × 50mm (sub-module only)
|
|
Weight
|
Approximately 0.3 kg (sub-module only)
|
|
Mounting Type
|
DIN-rail compatible (35mm standard); Panel-mountable (via optional bracket)
|
|
Compatibility
|
Yaskawa LASC main controllers (e.g., LASC-100), Sigma-5/Sigma-7 servo drives, MP2300iec motion controllers
|
|
Configuration Software
|
Yaskawa LASC Configurator (for encoder setup, error compensation, and synchronization tuning)
|
Key Features and Benefits
High-Resolution Encoder Support for Sub-Micron Positioning
The
YASKAWA LASC-100SUB supports high-resolution linear encoders (up to 25-bit absolute, 1,000,000 ppr incremental), enabling sub-micron positioning accuracy (±0.1 μm)—critical for applications like semiconductor wafer lithography or precision laser engraving. By processing encoder signals with advanced differential receivers, the sub-module minimizes noise interference, ensuring stable position feedback even in high-electromagnetic-interference (EMI) environments (e.g., near high-power laser systems). For example, in a flat-panel display manufacturing line, the
LASC-100SUB processes linear encoder data from a glass-handling stage, allowing the LASC system to position the glass with ±0.1 μm accuracy—essential for aligning pixel patterns during OLED deposition.
Multi-Axis Linear Synchronization for Complex Motion
Designed to work with Yaskawa’s LASC main controllers, the YASKAWA LASC-100SUB enables synchronization of up to 4 linear axes, eliminating motion errors caused by axis misalignment. This is particularly valuable in applications like gantry robots or dual-axis linear stages, where precise coordination between axes is required to avoid mechanical stress or product damage. The sub-module’s real-time synchronization logic (latency < 10 μs) ensures that all axes move in lockstep—for instance, in a precision cutting system, the LASC-100SUB synchronizes the X and Y linear stages to maintain a consistent cutting path, even at high speeds (up to 1 m/s), reducing material waste and improving cut quality.
Advanced Error Correction for Consistent Performance
The YASKAWA LASC-100SUB integrates multiple error correction features to address common linear motion challenges. Pitch/yaw/roll error compensation adjusts for mechanical misalignment of linear stages, while thermal expansion compensation accounts for temperature-induced dimensional changes in machine frames—critical for long-duration processes (e.g., 24-hour wafer inspection) where environmental conditions fluctuate. In a precision machining center, for example, the sub-module compensates for thermal expansion of the linear guideway, ensuring that the cutting tool maintains its position accuracy even as the machine heats up during operation. This reduces part tolerances to ±0.5 μm, meeting the strict requirements of aerospace or medical device manufacturing.
Seamless Integration with Yaskawa Automation Ecosystem
As a native component of Yaskawa’s LASC system, the YASKAWA LASC-100SUB integrates plug-and-play with LASC main controllers, Sigma series servo drives, and MP series motion controllers. Via the Yaskawa LASC Configurator software, technicians can easily configure encoder parameters, set up error compensation profiles, and monitor real-time position data—no custom programming required. For instance, when paired with a CACR-HR10BB servo drive and MP2300iec controller, the sub-module automatically shares encoder data with the controller, enabling closed-loop linear motion control. This integration reduces setup time by up to 40% compared to third-party linear control components and ensures compatibility across Yaskawa’s product lineup.
Compact Design and Low Power Consumption
The YASKAWA LASC-100SUB features a space-saving form factor (100×70×50mm) and DIN-rail mounting, making it ideal for crowded control cabinets—common in precision automation systems where multiple modules (drives, controllers, encoders) are required. Its low power consumption (24 VDC, 200 mA) reduces load on industrial power supplies and generates minimal heat, eliminating the need for additional cooling fans. In a semiconductor cleanroom, for example, multiple LASC-100SUB modules can be mounted on a single DIN rail alongside LASC main controllers and servo drives, optimizing cabinet space while maintaining the cleanroom’s strict environmental standards.
Related Models
- YASKAWA LASC-100SUB/KIT – Complete linear control package including the LASC-100SUB sub-module, LASC-100 main controller, high-resolution linear encoder (25-bit absolute), and LASC Configurator software—pre-configured for immediate deployment.
- YASKAWA LASC-200SUB – High-axis variant of the LASC-100SUB, supporting up to 8 axes of linear motion synchronization—designed for large-scale systems (e.g., multi-stage wafer processing tools).
- YASKAWA LASC-100SUB-T – Wide-temperature variant of the LASC-100SUB, operating from -10°C to +60°C—optimized for cold environments (e.g., cryogenic semiconductor testing) or high-temperature manufacturing (e.g., metal additive manufacturing).
- YASKAWA LASC-100SUB-E – EtherCAT-enabled variant, adding ultra-high-speed EtherCAT communication for integration into Industry 4.0 networks—ideal for applications requiring remote monitoring of linear motion data (e.g., smart factory MES systems).
- YASKAWA LASC-100SUB-S – Safety-certified variant (SIL 2) of the LASC-100SUB, with redundant encoder input paths and safe position monitoring—suitable for safety-critical linear motion applications (e.g., medical device assembly lines).
- YASKAWA LASC-100SUB-R – Rotary-to-linear conversion variant, adding software for converting rotary encoder data to linear position values—cost-effective for systems using existing rotary encoders (e.g., retrofitted CNC lathes).
Company & Service Highlights
Hainan Jinlin Mechanical and Electrical Equipment Co., Ltd. is a leading distributor of industrial control products, partnering with industry giants such as Yaskawa, Yokogawa, and Honeywell. With years of experience in linear motion control system integration, we offer:
- Genuine Yaskawa LASC Solutions: All YASKAWA LASC-100SUB sub-modules are 100% original, with full manufacturer documentation (including calibration records for encoder compatibility) to ensure compliance with precision motion standards. We also provide pre-configured LASC system bundles (e.g., LASC-100SUB + LASC-100 controller + linear encoder) for plug-and-play deployment.
- Expert Linear Motion Support: Our team of Yaskawa-certified engineers offers free pre-sales consultation to verify compatibility with your existing system (e.g., checking if the LASC-100SUB works with your Sigma-7 drive or MP2300iec controller). We also provide on-site services, including encoder calibration, error compensation tuning, and multi-axis synchronization setup.
- Fast Delivery & Stock Availability: We maintain regional stock of the YASKAWA LASC-100SUB and its related components, enabling delivery within 3-5 business days for urgent linear motion system repairs or upgrades. For large-volume orders (e.g., semiconductor factory expansions), we offer customized delivery schedules to align with your production timeline.
- Warranty & Maintenance: We offer a one-year warranty on the YASKAWA LASC-100SUB, with optional extended maintenance contracts that include annual encoder calibration, firmware updates, and priority technical support for LASC system troubleshooting.
Typical Application Areas
- Semiconductor Manufacturing: Enhancing linear stage positioning accuracy for wafer inspection and lithography systems, where the LASC-100SUB’s sub-micron precision ensures consistent chip fabrication.
- Flat-Panel Display Production: Synchronizing multi-axis linear stages for OLED glass handling and pixel alignment, reducing display defects (e.g., misaligned pixels) and improving production yield.
- Precision Machining: Compensating for thermal expansion and mechanical errors in linear guideways of CNC mills, enabling the machining of high-tolerance parts (e.g., medical implants, aerospace components).
- Laser Processing: Supporting high-speed linear motion synchronization for laser cutting/engraving systems, ensuring precise cut paths even at maximum travel speeds—critical for automotive interior component manufacturing.
If you need to verify compatibility of the YASKAWA LASC-100SUB with your linear motion system or require assistance with encoder setup and error compensation, please contact us today for tailored support.
